BRY55-400

Description
Silicon Controlled Rectifier, 0.8A I(T)RMS, 800mA I(T), 400V V(DRM), 400V V(RRM), 1 Element, TO-226AA
CategoryAnalog mixed-signal IC    Trigger device
File Size87KB,4 Pages
ManufacturerMotorola ( NXP )
Websitehttps://www.nxp.com
Download Datasheet Parametric Compare View All

BRY55-400 Overview

Silicon Controlled Rectifier, 0.8A I(T)RMS, 800mA I(T), 400V V(DRM), 400V V(RRM), 1 Element, TO-226AA

BRY55-400 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
Reach Compliance Codeunknown
Nominal circuit commutation break time20 µs
ConfigurationSINGLE
Maximum DC gate trigger current0.2 mA
Maximum DC gate trigger voltage0.8 V
Maximum holding current5 mA
JEDEC-95 codeTO-226AA
JESD-30 codeO-PBCY-T3
JESD-609 codee0
Maximum leakage current0.1 mA
On-state non-repetitive peak current8 A
Number of components1
Number of terminals3
Maximum on-state voltage1.7 V
Maximum on-state current800 A
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
Package shapeROUND
Package formCYLINDRICAL
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum rms on-state current0.8 A
Off-state repetitive peak voltage400 V
Repeated peak reverse voltage400 V
surface mountNO
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formTHROUGH-HOLE
Terminal locationBOTTOM
Maximum time at peak reflow temperatureNOT SPECIFIED
Trigger device typeSCR
Base Number Matches1
MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Order this document
by BRY55-30/D
Silicon Controlled Rectifiers
PNPN devices designed for high volume, line-powered consumer applications such
as relay and lamp drivers, small motor controls, gate drivers for larger thyristors, and
sensing and detection circuits. Supplied in an inexpensive TO-226AA (TO-92)
package which is readily adaptable for use in automatic insertion equipment.
Sensitive Gate Trigger Current — 200
µA
Maximum
Low Reverse and Forward Blocking Current — 100
µA
Maximum, TC = 125°C
Low Holding Current — 5 mA Maximum
Glass-Passivated Surface for Reliability and Uniformity
BRY55-30*
thru 600*
SCRs
0.8 AMPERE RMS
30 TO 600 VOLTS
CASE 29-04
(TO-226AA)
STYLE 3
WITH TO-18 LEADFORM*
MAXIMUM RATINGS
(TJ = 25°C unless otherwise noted.)
Rating
Peak Repetitive Forward and Reverse Blocking Voltage(1)
(RGK = 1000
Ω,
TJ = 25 to 125°C)
Marking: BRY55-1 . . . BRY55-30
-2 . . . BRY55-60
-3 . . . BRY55-100
-4 . . . BRY55-200
-6 . . . BRY55-400
-7 . . . BRY55-500
-8 . . . BRY55-600
Forward Current RMS (All Conduction Angles)
Peak Forward Surge Current, TA = 25°C
(1/2 Cycle, Sine Wave, 60 Hz)
Circuit Fusing Considerations, TA = 25°C
(t = 8.3 ms)
Peak Gate Power — Forward, TA = 25°C
Peak Gate Current Forward, TA = 25°C
(300
µs,
120 PPS)
Peak Gate Voltage — Reverse
Operating Junction Temperature Range @ Rated VRRM and VDRM
Storage Temperature Range
Symbol
VRRM, VDRM
30
60
100
200
400
500
600
IT(RMS)
ITSM
I2t
PGM
IGFM
VGRM
TJ
Tstg
0.8
8
0.15
0.1
1
5
–40 to +125
–40 to +150
+230
Amp
Amps
A2s
Watt
Amp
Volts
°C
°C
°C
Value
Unit
Volts
Lead Solder Temperature ( 1.5 mm from case, 10 s max.)
*European part numbers only. Package is Case 29 with Leadform 18.
t
1. VDRM and VRRM for all types can be applied on a continuous basis. Ratings apply for zero or negative gate voltage; however, positive gate
voltage shall not be applied concurrent with negative potential on the anode. Blocking voltages shall not be tested with a constant current
source such that the voltage ratings of the devices are exceeded.
Motorola Thyristor Device Data
©
Motorola, Inc. 1995
1
