65980-002LF datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 65980-002LF

65980-002LF: DescriptionBoard Connector, 35 Contact(s), 1 Row(s), Female, 0.1 inch Pitch, Crimp Terminal, Latch, Black Insulator, Plug, LEAD FREE; CategoryThe connector The connector; File Size169KB，2 Pages; ManufacturerAmphenol; Websitehttp://www.amphenol.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

65980-002LF Overview

Board Connector, 35 Contact(s), 1 Row(s), Female, 0.1 inch Pitch, Crimp Terminal, Latch, Black Insulator, Plug, LEAD FREE

65980-002LF Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	LEAD FREE
Reach Compliance Code	compliant
ECCN code	EAR99
body width	0.1 inch
subject depth	0.55 inch
body length	3.5 inch
Body/casing type	PLUG
Connector type	BOARD CONNECTOR
Contactor design	PREASSEM CONN
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
contact mode	RECTANGULAR
Contact resistance	2 mΩ
Contact style	SQ PIN-SKT
DIN compliance	NO
Durability	1000 Cycles
Filter function	NO
IEC compliance	NO
Insulation resistance	5000000000 Ω
Insulator color	BLACK
insulator material	POLYPHELYNENE
MIL compliance	NO
Manufacturer's serial number	65980
Plug contact pitch	0.1 inch
Mixed contacts	NO
Installation option 1	LATCH
Installation option 2	LOCKING
Installation type	CABLE
Number of rows loaded	1
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
polarization key	POLARIZED HOUSING
Guideline	UL
reliability	COMMERCIAL
Termination type	CRIMP
Total number of contacts	35
UL Flammability Code	94V-0
Maximum wire diameter	22 AWG
Minimum wire diameter	36 AWG
Base Number Matches	1

Preview

Download Datasheet

View All

PDM: Rev:M

STATUS:

Released

Printed: Sep 15, 2009
