Oscilent Corporation IF SAW Filter | 813-IF75.0M-C
Page 1 of 2
IF SAW Filter
Part Number
Package
Application
Last Modified
813-IF75.0M-C
.
TYPE :
13.3 x 6.5 SMD
Base Station & Repeater
May 24 2003
75.0 MHz Bandpass Filter
19.8 MHz Bandwidth
PART NUMBER :
813-IF75.0M-C
..
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Center Frequency
Insertion Loss
1dB Bandwidth
3dB Bandwidth
33dB Bandwidth
40dB Bandwidth
Passband Ripple
Group Delay Variation
Absolute Delay
Ultimate Rejection
Substrate Material
Minimum
74.92
-
19.1
19.8
-
-
-
-
-
-
-
Typical
75.00
22.5
19.5
20.0
21.7
22.0
0.75
50
1.10
42
LN
Maximum
75.08
24.0
-
-
22.0
22.5
1.0
120
-
-
-
Units
MHz
dB
MHz
MHz
MHz
MHz
dB
nsec
µsec
dB
-
* Custom SAW IF Filters available. Contact Oscilent for assistance.
.
PACKAGE OUTLINE
(mm)
TEST FIXTURE
L2 =
330nH
C2 = 10pF
Source/Load Impedance = 50 ohms
Part No.:
813-IF75.0M-C
