Oscilent Corporation IF SAW Filter | 813-IF70.0M-CA
Page 1 of 1
IF SAW Filter
Part Number
Package
Application
Last Modified
813-IF70.0M-CA
.
TYPE :
13.3 x 6.5 SMD
Base Station & Repeater
May 30 2003
70.0 MHz Bandpass Filter
9.7 MHz Bandwidth
PART NUMBER :
813-IF70.0M-CA
..
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Center Frequency
Insertion Loss
1dB Bandwidth
3dB Bandwidth
40dB Bandwidth
Passband Ripple (Fo ±4.0MHz)
Group Delay Variation (Fo ±4.0MHz)
Ultimate Rejection
Temperature Coefficient
Minimum
-
-
9.2
9.7
-
-
-
40
-
Typical
70.00
22.5
9.3
9.8
11.7
0.80
60
42
-18
Maximum
-
24.0
-
-
12.0
1.0
150
-
-
Units
MHz
dB
MHz
MHz
MHz
dB
nsec
dB
ppm/K
* Custom SAW IF Filters available. Contact Oscilent for assistance.
.
PACKAGE OUTLINE
(mm)
TEST FIXTURE
L1 =
L2 =
150nH
(330+15)nH
C1 = 33pF
C2 = 51pF
Source/Load Impedance = 50 ohms
Part No.:
813-IF70.0M-CA
