Oscilent Corporation RF SAW Filter | 802-RF1950.0M-A
Page 1 of 3
RF SAW Filter
Part Number
Package
Application
Last Modified
802-RF1950.0M-A
.
TYPE :
3.0 x 3.0 SMD
WCDMA
Jan. 01, 2007
WCDMA, RF-Tx SAW Filter
PART NUMBER :
802-RF1950.0M-A
..
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Center Frequency (Fo)
Insertion Loss
Stop Band Attenuation:
Condition
-
1920.0~ 1980.0 MHz
D.C.~1840.0 MHz
1840.0~ 1900.0 MHz
2000.0~ 2030.0 MHz
2030.0~2060.0 MHz
2060.0~ 5000 MHz
Amplitude Ripple
Source Impedence (single ended)*
Load Impendance (single ended)*
VSWR
Maximum DC Voltage
Maximum Input Power
Operating Temperature
1920.0~ 1980.0 MHz
-
-
1920.0~ 1980.0 MHz
-
-
-
Minimum
-
-
20
10
4.5
20
22
-
-
-
-
-
-
-30
Typical
1950.0
2.8
31
17
9
50
26
1.4
50
50
1.9
-
-
-
Maximum
-
4.0
-
-
-
-
-
2.4
-
-
2.4
5
10
+80
dBp-p
ohm
ohm
-
V
dBm
ºC
dB
Units
MHz
dB
* No Matching Network (Ref. Testing Environment Circcuit as shown below)
.
PACKAGE OUTLINE
(mm)
PIN LAYOUT
A
B
C
D
E
F
Ground
Out
Ground
Ground
In
Ground
TEST FIXTURE
