Oscilent Corporation | 738 Series Ceramic Filter
Page 1 of 2
Filters
Series Number
Package
Description
Last Modified
738
Filter FEATURES
- Ultra small size
- 6.3mm profile
- Broadband width
- High selectivity
- 6 element
- RoHS Compliant
Ceramic LTM/W
455 KHz 6 Element
Jan. 01 2008
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS / PART NUMBER
GUIDE
PART NO.
6dB
Bandwidth
KHz min.
50dB Bandwidth
KHz max.
±35
±30
±24
±20
±15
±12.5
±10
±9
±7.5
±9
±7.5
Pass Band
Ripple
dB max.
2
2
2
2
2
2
2
2
2
2
50
Spurious
Attenuation
fn ±100KHz
dB min.
40
40
40
40
40
40
40
40
40
60
60
Insertion
Loss
dB max.
4
4
4
6
6
6
6
6
6
6
6
In/Output
Impedance
Kohm
1
1.5
1.5
1.5
1.5
2
2
2
2
2
2
738-455-AW
738-455-BW
738-455-CW
738-455-DW
738-455-EW
738-455-FW
738-455-GW
738-455-HW
738-455-IW
738-455-HT
738-455-IT
±17.5
±15
±12.5
±10
±7.5
±6
±4.5
±3
±2
±3
±2
NOTE:
Deviations on all parameters available. Please consult Oscilent for details.
DEFINITIONS:
Click on the characteristic names above, for definitions of the particular characteristic.
http://www.oscilent.com/spec_pages/Filters/F-738.html
4/3/2008
