WDM
Pump/Signal WDM
Parameter
Insertion Loss (Pass Band)
Insertion Loss (Reflect Band)
Isolation (Pass Band)
Isolation (Reflect Band)
Return Loss
Directivity
PDL
PMD
Maximum Power Handling
Operating Temperature
Storage Temperature
Package Dimension
980/1550 nm
1480/1550 nm
≤ 0.8 dB (1520-1600 nm) ≤ 0.7 dB (1530-1580 nm)
≤ 0.7 dB (930-1000 nm) ≤ 0.6 dB (1440-1490 nm)
≥ 30 dB
≥ 18 dB
≥ 12 dB
≥ 50 dB
≥ 55 dB
≤ 0.1 dB
≤ 0.05 ps
300 mW
- 0° C ~ + 65° C
- 40° C ~ + 85° C
Bare Fiber (B)
5.5 mm () x 35 mm (L)
900μm loose tube (L)
5.5 mm () x 40 mm (L)
Note 1: All values specified are without connectors.
Note2: Higher performance specifications are available upon request.
Note3: Fiber Type – Corning SMF-28e and HI 1060.
Note4: Over operating temperature, all SOP.
W D
-
14: 1480nm pump
98: 980nm pump
-
Fiber Length
A: 1 meter
B: 1.5 meter
S: Special
-
-
Pigtail Style
(=Package style)
B: bare fiber
L: 900
m
loose tube
Connector
0: None
1: FC/PC
2: FC/APC
3: SC/ PC
4: SC/APC
5: FC/SPC
6: SC/SPC
7: LC/UPC
8: LC/SPC
9: Special
A: FC/UPC
B: SC/UPC
C: ST
