D Subminiature
Part numbers with metal bracket and
captive nut M3
Shell Layout
size
P/N without pushfit
P/N with mounting hole
diameter 3,2 and pushfit
Combo D
®
/European Version
Part numbers with plastic bracket
captive nut M3
P/N without pushfit
P/N with mounting hole
diameter 3,2 and pushfit
Solder pin 90° – European footprint, sizes DE – DC, with empty size 8 cavities, with different brackets
Part numbers with plastic bracket with
grounding bracket and captive nut M3
P/N without pushfit
P/N with mounting hole
diameter 3,2 and pushfit
DE
DA
DA
DA
DA
DB
DB
DB
DB
DB
DC
DC
DC
DC
DC
DC
5W1
7W2
11W1
3W3
3WK3
5W5
9W4
13W3
17W2
21W1
8W8
13W6
17W5
21WA4
25W3
27W2
DEM-5W1S-1A9N-A191-A197
DAM-7W2S-1A9N-A191-A197
DAM-11W1S-1A9N-A191-A197
DAM-3W3S-1A9N-A197
DAM-3WK3S-1A9N-A197
DBM-5W5S-1A9N-A197
DBM-9W4S-1A9N-A191-A197
DBM-13W3S-1A9N-A191-A197
DBM-17W2S-1A9N-A191-A197
DBM-21W1S-1A9N-A191-A197
DCM-8W8S-1A9N-A197
DCM-13W6S-1A9N-A191-A197
DCM-17W5S-1A9N-A191-A197
DCM-21WA4S-1A9N-A191-A197
DCM-25W3S-1A9N-A191-A197
DCM-27W2S-1A9N-A191-A197
DEM-5W1S-1A9N-A191-A197-146
DAM-7W2S-1A9N-A191-A197-146
DAM-11W1S-1A9N-A191-A197-146
DAM-3W3S-1A9N-A197-146
DAM-3WK3S-1A9N-A197-146
DBM-5W5S-1A9N-A197-146
DBM-9W4S-1A9N-A191-A197-146
DBM-13W3S-1A9N-A191-A197-146
DBM-17W2S-1A9N-A191-A197-146
DBM-21W1S-1A9N-A191-A197-146
DCM-8W8S-1A9N-A197-146
DCM-13W6S-1A9N-A191-A197-146
DCM-17W5S-1A9N-A191-A197-146
DCM-21WA4S-1A9N-A191-A197-146
DCM-25W3S-1A9N-A191-A197-146
DCM-27W2S-1A9N-A191-A197-146
DEM-5W1S-1ATN-A191-A197
DAM-7W2S-1ATN-A191-A197
DAM-11W1S-1ATN-A191-A197
DAM-3W3S-1ATN-A197
DAM-3WK3S-1ATN-A197
DBM-5W5S-1ATN-A197
DBM-9W4S-1ATN-A191-A197
DBM-13W3S-1ATN-A191-A197
DBM-17W2S-1ATN-A191-A197
DBM-21W1S-1ATN-A191-A197
DCM-8W8S-1ATN-A197
DCM-13W6S-1ATN-A191-A197
DCM-17W5S-1ATN-A191-A197
DCM-21WA4S-1ATN-A191-A197
DCM-25W3S-1ATN-A191-A197
DCM-27W2S-1ATN-A191-A197
DEM-5W1S-1ATN-A191-A197-146
DAM-7W2S-1ATN-A191-A197-146
DAM-11W1S-1ATN-A191-A197-146
DAM-3W3S-1ATN-A197-146
DAM-3WK3S-1ATN-A197-146
DBM-5W5S-1ATN-A197-146
DBM-9W4S-1ATN-A191-A197-146
DBM-13W3S-1ATN-A191-A197-146
DBM-17W2S-1ATN-A191-A197-146
DBM-21W1S-1ATN-A191-A197-146
DCM-8W8S-1ATN-A197-146
DCM-13W6S-1ATN-A191-A197-146
DCM-17W5S-1ATN-A191-A197-146
DCM-21WA4S-1ATN-A191-A197-146
DCM-25W3S-1ATN-A191-A197-146
DCM-27W2S-1ATN-A191-A197-146
DEM-5W1S-1AVN-A191-A197
DAM-7W2S-1AVN-A191-A197
DAM-11W1S-1AVN-A191-A197
DAM-3W3S-1AVN-A197
DAM-3WK3S-1AVN-A197
DBM-5W5S-1AVN-A197
DBM-9W4S-1AVN-A191-A197
DBM-13W3S-1AVN-A191-A197
DBM-17W2S-1AVN-A191-A197
DBM-21W1S-1AVN-A191-A197
DCM-8W8S-1AVN-A197
DCM-13W6S-1AVN-A191-A197
DCM-17W5S-1AVN-A191-A197
DCM-21WA4S-1AVN-A191-A197
DCM-25W3S-1AVN-A191-A197
DCM-27W2S-1AVN-A191-A197
DEM-5W1S-1AVN-A191-A197-146
DAM-7W2S-1AVN-A191-A197-146
DAM-11W1S-1AVN-A191-A197-146
DAM-3W3S-1AVN-A197-146
DAM-3WK3S-1AVN-A197-146
DBM-5W5S-1AVN-A197-146
DBM-9W4S-1AVN-A191-A197-146
DBM-13W3S-1AVN-A191-A197-146
DBM-17W2S-1AVN-A191-A197-146
DBM-21W1S-1AVN-A191-A197-146
DCM-8W8S-1AVN-A197-146
DCM-13W6S-1AVN-A191-A197-146
DCM-17W5S-1AVN-A191-A197-146
DCM-21WA4S-1AVN-A191-A197-146
DCM-25W3S-1AVN-A191-A197-146
DCM-27W2S-1AVN-A191-A197-146
For performance class 1 replace A191 with A190.
For performance class 3 delete A191.
For captive nut 4-40 UNC thread replace 1A9N with 1A7N and
3W3/3WK3 (keyed)/5W5 and 8W8 without signal
1AHN with 1A8N.
contacts.
For pushfit 90° pcb hole diameter 3,2 mm replace 146 with 162.
Socket
A
C
B
A2
2
1
7W2S
A1
D
ITT
5
4
3
CANNON
10
°
3,7
±0,3
E
11,57
q
L
±0,2
q
14,9
±0,2
2,54
q
Ø 0,6
q
For contact cavity arrangements, see page 53.
For pcb hole pattern, see page 57 – 59
for coaxial or pages 72 – 75 for high power
contacts.
For mounting methods, see page 86 – 87.
For panel cut-outs, see our D Subminiature
catalogue.
7,3
±0,15
Dimensions
Shell
size
A
±
0,38
B
±
0,13
C
±
0,13
D
±
0,13
E
±
0,13
F
±
0,25
10,9
10,9
10,9
10,9
L
+
0,2
W
±
0,4
DE
DA
DB
DC
30,8
39,15
53,05
69,3
16,35
24,65
38,4
54,85
25
33,3
47.05
63,5
7,9
7,9
7,9
7,9
12,55
12,55
12,55
12,55
0,8
0,8
0,8
0,8
6,95
6,95
6,95
6,95
W
F
33
