KSA1370
KSA1370
Crt Display, Video Output
• High Voltage
• Low Reverse Transfer Capacitance : C
re
= 1.7pF
1
TO-92L
1. Emitter 2. Collector 3. Base
PNP Epitaxial Silicon Trnsistor
Absolute Maximum Ratings
T
a
=25°C unless otherwise noted
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CP
P
C
T
J
T
STG
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current (DC)
Collector Current (Pulse)
Collector Power Dissipation
Junction Temperature
Storage Temperature
Parameter
Ratings
-200
-200
-5
-100
-200
1.0
150
-55 ~ 150
Units
V
V
V
mA
mA
W
°C
°C
Electrical Characteristics
T
a
=25°C unless otherwise noted
Symbol
BV
CBO
BV
CEO
BV
EBO
I
CBO
I
EBO
h
FE
V
CE
(sat)
V
BE
(on)
f
T
C
ob
C
re
Parameter
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector Cut-off Current
Emitter Cut-off Current
DC Current Gain
Collector-Emitter Saturation Voltage
Base-Emitter On Voltage
Current Gain Bandwidth Product
Output Capacitance
Reverse Transfer Capacitance
Test Condition
I
C
= -10µA, I
E
=0
I
C
= -1mA, I
B
=0
I
E
= -10µA, I
C
=0
V
CB
= -150V, I
E
=0
V
EB
= -4V, I
C
=0
V
CE
= -10V, I
C
= -10mA
I
C
= -20mA, I
B
= -2mA
I
C
= -20mA, I
B
= -2mA
V
CE
= -30V, I
C
= -10mA
V
CB
= -30V, f=1MHz
V
CB
= -30V, f=1MHz
150
2.6
1.7
100
Min.
-200
-200
-5
-0.1
-0.1
320
-0.6
-1.0
V
V
MHz
pF
pF
Typ.
Max.
Units
V
V
V
µA
µA
©2002 Fairchild Semiconductor Corporation
Rev. C, December 2002
KSA1370
Typical Characteristics
-160
1000
Pulse Test
I
C
[mA], COLLECTOR CURRENT
-140
V
CE
= - 5V
Pulse Test
-100
I
B
=-500
µ
A I
B
=-450
µ
A
I
B
=-400
µ
A
I
B
=-350
µ
A
I
B
=-300
µ
A
I
B
=-250
µ
A
I
B
=-200
µ
A
I
B
=-150
µ
A
I
B
=-100
µ
A
I
B
=-50
µ
A
I
B
=0
h
FE
, DC CURRENT GAIN
-120
100
-80
-60
10
-40
-20
-0
-20
-40
-60
-80
-100
-120
-140
-160
1
-0.1
-1
-10
-100
V
CE
[V], COLLECTOR-EMITTER VOLTAGE
I
C
[mA], COLLECTOR CURRENT
Figure 1. Static Characteristic
Figure 2. DC current Gain
V
CE
(sat), V
BE
(sat)[V], SATURATION VOLTAGE
-10
100
I
C
= - 10 I
B
Pulse Test
f=1.0MHz
I
E
=0 (C
ob
)
C
ob
[pF] C
ib
[pF], CAPACITANCE
I
C
=0 (C
ib
)
C
ib
-1
V
BE
(sat)
10
-0.1
V
CE
(sat)
C
ob
-0.01
-0.1
1
-1
-10
-100
-1
-10
-100
-1000
V
CB
[V], COLLECTOR-BASE VOLTAGE
I
C
[mA], COLLECTOR CURRENT
V
EB
[V], EMITTER-BASE VOLTAGE
Figure 3. Base-Emitter Saturation Voltage
Collector-Emitter Saturation Voltage
Figure 4. Collector Output Capacitance
f
T
[MHz], CURRENT GAIN-BANDWIDTH PRODUCT
1000
-1000
V
CE
= -10V
Ta=25 C
Single Pulse
I
C
MAX(Pulse)
s
0
µ
50
o
I
C
[A], COLLECTOR CURRENT
-100
I
C
MAX(DC)
s
1m ms
10
100
-10
10
-1
-10
-100
-1
-1
-10
-100
-1000
I
C
[mA], COLLECTOR CURRENT
V
CE
[V], COLLECTOR-EMITTER VOLTAGE
Figure 5. Current Gain Bandwidth Product
Figure 6. Safe Operating Area
©2002 Fairchild Semiconductor Corporation
V
CEO
MAX
Rev. C, December 2002
