SPECIFICATIONS
Current rating
Contact material:
Insulator material:
Contact plating:
Insulator resistance:
Withstanding:
Operating temperature:
Positions
10
12
14
16
20
24
26
30
34
40
44
50
56
60
64
A
3 amps
Phosphor bronze
Polyester, UL 94V-0
Gold, tin or duplex
5,000 megohms min.
500VAC
-40C° to +105C°
C
21.84
24.38
26.92
29.46
34.54
39.62
42.16
47.24
52.32
59.94
65.02
72.64
80.26
85.34
90.42
D
27.94
30.48
33.02
38.10
40.64
46.72
48.26
53.34
58.42
66.04
71.12
78.71
86.36
91.44
96.62
Series
Positions
Mounting
Latch
Plating
Options
LHD
XX
XX
XX
XX
XX
Latch 10, 12, 14, 16, 20, ST=Straight
SL=Short latch GDXX=Gold
XX=Blank if flash; [blank]=None
header 24, 30, 34, 40, 44, RA=Right angle LL=Long latch SGXX=Selective gold 15, 30, 50µ” gold SPL=Custom pin length
50, 56, 60, 64
NL=No latches TN=Tin
PF=Press fit (ST only)
Date
10/7/05
Approved
Tom
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
Date
02/10/97
02/10/97
02/10/97 Part No.:
B
C
D
E
A
B
10.16 32.00
12.70 34.54
15.24 37.08
17.78 39.62
22.85 44.70
27.94 49.78
30.48 52.32
35.56 57.40
40.64 62.48
48.26 70.10
53.34 75.18
60.96 82.80
68.58 90.42
73.66 95.50
78.74 100.58
C
D
E
F
RoHS compliant
Rev.
A GD
Description
F
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
G
LHD-XX-XX-XX-XX
7
8
9
1
2
3
4
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
Description: Male shrouded latch header
