SAW Bandpass Filter 263001B
1. Features
IF bandpass filter
High attenuation
Single-ended operation
DIP Package
Maximum Storage Temperature Range : -40
℃
~ 85
℃
Electrostatics Sensitive Device (ESD)
2. Package Dimension
12.7±0.5
5.5max 6.0max
7.6±0.2
ITF 08A001
263001B
300-30.5M
0.45±0.05
20.3±0.5
2.5±0.2
Package : D2012
Pin Configuration
1
Input
Output
Ground
Case ground
Dimensions shown are nominal in millimeters
Base : Fe(SPCC), Au plating over Ni plated
Cap : Cu & Cr Alloy, Ni Plated
Termination : Kovar, Au Plated
5
2, 4
3, 6
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
263001B
2008-12-24
NM8016-CS01
1/5
12.7±0.2
2.5±0.2
SAW Bandpass Filter 263001B
3. Specifications
Fo = 300.0 MHz
Terminating source impedance
Terminating load impedance
: 50Ω and matching network
: 50Ω and matching network
Operating Temperature Range : +25℃
℃
Minimum
Typical
Maximum
Center Frequency
Insertion Loss
1dB Bandwidth
3dB Bandwidth
40dB Bandwidth
Amplitude Ripple (fo±15.0 MHz)
Group Delay Variation (fo±15.0 MHz)
Absolute Delay
Ultimate Rejection
Out of Band-gain
Fo +/- 16.0MHz
Fo +/- 18.5MHz
Temperature Coefficient of Frequency
MHz
dB
MHz
MHz
MHz
dB
nsec
usec
dB
-
-
30.4
-
-
-
-
-
45
300.0
31.3
30.5
30.85
32.4
0.55
25
2.47
50
-
33.0
-
-
32.5
1.0
50
-
-
dB
dB
ppm/°C
15
40
-
23
50
-18
-
Notes :
1)
2)
3)
All specifications are based on the matching schematic shown below
All specifications are measured by Agilent Network analyzer and full 2 port calibration at room temperature
All attenuation measurements are measured relative to insertion loss
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
263001B
2008-12-24
NM8016-CS01
2/5
SAW Bandpass Filter 263001B
4. Matching Schematic
( Actual matching values may vary due to PCB layout and parasitics )
Input
50
Ω
L1
L2
Output
50
Ω
C1
C2
L1 = L2 = 12nH
C1 = C2 = 24pF
5. Marking Configuration
ITF
1)
08A001
2)
263001B
3)
300
4)
-30.5M
5)
1) Manufacturer name
2) Lot Number
3) Part Number
4) Center Frequecy
5) 1dB-Bandwidth
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
263001B
2008-12-24
NM8016-CS01
3/5
SAW Bandpass Filter 263001B
6. Typical Performance ( at +25℃ )
℃
CH1
CH2
S21
S21
LOG
DEL
1 dB/
71.03 ns/
REF -30.98 dB
REF 2.464 us
11 Jan 2008 15:48:01
1: 0. 0000 dB
0. 000 000 MHz
3: -9 . 8266 ns
30. 000 000 MHz
CH1 Markers
BW
:
Cor
30. 841512 MHz
REF=1
cent : 299 . 936370 MHz
Q: 9. 7251
1
2
1_loss : -31 . 251 dB
3
Smo
Cor
3
CH2 Markers
mean: 2. 4779 us
s. dev : 5. 4316 ns
p-p : 27. 053 ns
2
4
REF=2
CENTER 300 . 000 000 MHz
SPAN 37. 000 000 MHz
CH1
S21
LOG
10 dB/
REF -31.38 dB
11 Jan 2008 15:45:16
1: 0. 0000 dB
0. 000 000 MHz
*
CH1 Markers
Cor
1
2
BW
:
32. 376060 MHz
REF=1
cent : 299 . 937121 MHz
Q: 9. 2642
1_loss : -31 . 424 dB
Hld
3
4
CENTER 300 . 000 000 MHz
SPAN 83. 000 000 MHz
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
263001B
2008-12-24
NM8016-CS01
4/5
SAW Bandpass Filter 263001B
CH1
CH2
S21
S21
LOG
LOG
1 dB/
1 dB/
REF -30.98 dB
REF -31.46 dB
11 Jan 2008 15:47:48
1: 0. 0000 dB
0. 000 000 MHz
3: - . 45470 dB
30. 000 000 MHz
CH1
CH2
*
S21
S21
LOG
LOG
10 dB/
10 dB/
REF -31.42 dB
REF -31.42 dB
11 Jan 2008 15:47:04
1: 0. 0000 dB
0. 000 000 MHz
1: 0. 0000 dB
0. 000 000 MHz
CH1 Markers
BW
:
Cor
30. 498602 MHz
REF=1
Cor
1
CH1 Markers
2: -23 . 724 dB
-16 . 0000 MHz
3: -22 . 570 dB
16. 0000 MHz
REF=1
cent : 299 . 929556 MHz
Q: 9. 8342
1
2
1_loss : -31 . 220 dB
Hld
3
4
2
3
3
2
Cor
CH2 Markers
mean : -31 . 197 dB
s. dev : . 08760 dB
p-p : . 54980 dB
Hld
Cor
CH2 Markers
3
2
2: -60 . 078 dB
-18 . 5000 MHz
3: -53 . 476 dB
18. 5000 MHz
REF=2
REF=1
CENTER 300 . 000 000 MHz
SPAN 37. 000 000 MHz
CENTER 300 . 000 000 MHz
SPAN 83. 000 000 MHz
CH1
S21
LOG
10 dB/
REF -33.12 dB
11 Jan 2008 15:49:15
1: 0. 0000 dB
0. 000 000 MHz
CH1
CH2
S11
S22
SWR
SWR
2 /
2 /
REF 1.765
REF 1.829
11 Jan 2008 15:48:51
1: 1. 7652
300 . 000 000 MHz
2: 1. 8298
300 . 000 000 MHz
CH1 Markers
2: -53 . 896 dB
300 . 000 MHz
1
3: -53 . 548 dB
600 . 000 MHz
REF=1
Cor
1
Cor
2
2
3
START
. 010 000 MHz
STOP 1 000 . 000 000 MHz
CENTER 300 . 000 000 MHz
SPAN 83. 000 000 MHz
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
263001B
2008-12-24
NM8016-CS01
5/5
