SAW Bandpass Filter 203416B
1. Features
IF Bandpass Filter
High Attenuation
Single-Ended Operation
DIP Package
Maximum Storage Temperature Range : -40
℃
~ 85
℃
Electrostatics Sensitive Device (ESD)
2. Package Dimension
12.7±0.5
5.5max 6.0max
7.6±0.2
2.5±0.2
Output
Ground
Case ground
ITF 04A001
203416B
27.3±0.5
Package : D2712
0.45±0.05
Pin Configuration
1
Input
Dimensions shown are nominal in millimeters
Base : Fe(SPCC), Au plating over Ni plated
Cap : Cu & Cr Alloy, Ni Plated
Termination : Kovar, Au Plated
4
2, 5
3, 6
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
2004-05-04
NW3012-CS04
1/5
17.7±0.2
2.5±0.2
203416B
SAW Bandpass Filter 203416B
3. Specifications
Fo = 82.5 MHz
Terminating source impedance
Terminating load impedance
: 50Ω and matching network
: 50Ω and matching network
Minimum
Center Frequency
Insertion Loss
1Db Bandwidth
3dB Bandwidth
40dB Bandwidth
Amplitude Ripple (Fo +/- 0.5 MHz)
Group Delay Variation (Fo +/- 0.5 MHz)
Absolute Delay
Ultimate Rejection
Temperature Coefficient of Frequency
MHz
dB
MHz
MHz
MHz
dB
nsec
usec
dB
ppm/°C
2
82.46
-
1.0
-
-
-
-
-
40
-
Typical
82.5
22.5
1.06
1.25
2.04
1.0
150
3.37
45
-0.03
Maximum
82.54
25.0
-
-
2.1
1.5
250
-
-
-
Notes :
1)
2)
3)
All specifications are based on the matching schematic shown below
All specifications are measured by Agilent Network analyzer and full 2 port calibration
All attenuation measurements are measured relative to insertion loss
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
203416B
2004-05-04
NW3012-CS04
2/5
SAW Bandpass Filter 203416B
4. Matching Schematic
( Actual matching values may vary due to PCB layout and parasitics )
Input
50
Ω
L2
L3
Output
50
Ω
L1
L4
L1 = L4 = 56 nH
L2 = L3 = 47 nH
5. Marking Configuration
ITF
1)
04A001
2)
203416B
3)
1) Manufacturer name
2) Lot Number
3) Part Number
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
203416B
2004-05-04
NW3012-CS04
3/5
SAW Bandpass Filter 203416B
6. Typical Performance ( at +25℃ )
CH1
S21
LOG
10 dB/
REF -23.15 dB
3 May 2004 13:08:45
1: 0. 0000 dB
0. 000 000 MHz
203416B
CH1 Markers
1
Cor
2
BW
:
cent :
2. 046603
82. 524842
MHz
MHz
REF=1
Q: 40. 323
1_loss : -23 . 157 dB
3
4
CENTER 82. 500 000 MHz
SPAN
6. 000 000 MHz
CH2
CH4
S21
S21
LOG
DEL
1 dB/
300 ns/
REF -23.15 dB
REF 3.9 us
3 May 2004 13:09:32
1: 0. 0000 dB
0. 000 000 MHz
3: -55 . 313 ns
1. 000 000 MHz
203416B
CH2 Markers
BW
:
cent :
1
2
1. 253466
82. 505503
MHz
MHz
REF=1
Q: 65. 822
1_loss : -23 . 148 dB
Cor
Smo
3
2
4
3CH4 Markers
mean : 3. 3764 us
s. dev : 28. 464 ns
p-p : 124 . 17 ns
REF=2
Cor
4
CENTER 82. 500 000 MHz
2
SPAN
2. 000 000 MHz
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
203416B
2004-05-04
NW3012-CS04
4/5
SAW Bandpass Filter 203416B
CH2
CH4
S21
S21
LOG
LOG
1 dB/
1 dB/
REF -23.15 dB
REF -23.75 dB
3 May 2004 13:09:45
1: 0. 0000 dB
0. 000 000 MHz
3: - . 07450 dB
1. 000 000 MHz
CH1
S21
LOG
10 dB/
REF -24.99 dB
3 May 2004 13:11:36
1: 0. 0000 dB
0. 000 000 MHz
203416B
CH2 Markers
BW
:
cent :
1
2
1. 066735
82. 501751
MHz
MHz
REF=1
203416B
CH1 Markers
1
2: -16 . 584 dB
50. 7000 MHz
3: -17 . 738 dB
68. 9000 MHz
REF=1
Q: 77. 340
1_loss : -23 . 144 dB
2
3
3
2
4
3
CH4 Markers
Cor
mean : -23 . 109 dB
s. dev : . 16320 dB
p-p : . 90200 dB
Cor
REF=2
CENTER 82. 500 000 MHz
4
2
SPAN
2. 000 000 MHz
START
. 010 000 MHz
STOP 200 . 000 000 MHz
CH1
CH3
S11
S22
SWR
SWR
5 /
5 /
REF 0
REF 0
3 May 2004 13:10:37
1: 4. 7156
82. 500 000 MHz
2: 6. 9922
82. 500 000 MHz
CH1
CH3
S11
S22
1 U FS
1 U FS
1: 41. 332
2: 22. 785
77. 184
71. 484
3 May 2004 13:10:14
148 . 90 nH
82. 500 000 MHz
137 . 90 nH
82. 500 000 MHz
203416B
203416B
2
Cor
Cor
1
Cor
Cor
1
2
CENTER 82. 500 000 MHz
SPAN
6. 000 000 MHz
CENTER 82. 500 000 MHz
SPAN
6. 000 000 MHz
I T F Co., Ltd.
102-901, Bucheon Technopark 364,
Samjeong-Dong, Ojeong-Gu, Bucheon-City,
Gyounggi-Do, Korea 421-809
Part No.
Rev. Date
Rev.
203416B
2004-05-04
NW3012-CS04
5/5
