CMPZDC2V4 THRU CMPZDC47V
SURFACE MOUNT
DUAL, COMMON CATHODE
SILICON ZENER DIODES
2.4 VOLTS THRU 47 VOLTS
350mW
w w w. c e n t r a l s e m i . c o m
DESCRIPTION:
The CENTRAL SEMICONDUCTOR CMPZDC2V4
series dual silicon Zener diode is a highly quality
voltage regulator, connected in a common cathode
configuration, for use in industrial, commercial,
entertainment and computer applications.
MARKING CODE: SEE MARKING CODES ON
ELECTRICAL CHARACTERISTICS TABLE
SOT-23 CASE
MAXIMUM RATINGS:
(TA=25°C)
Power Dissipation
Operating and Storage Temperature
Thermal Resistance
SYMBOL
PD
TJ, Tstg
Θ
JA
UNITS
mW
°C
°C/W
350
-65 TO +175
429
ELECTRICAL CHARACTERISTICS PER DIODE:
(TA=25°C) VF=0.9V MAX @ IF=10mA (for all types)
ZENER
VOLTAGE
VZ @ IZT
MIN
V
CMPZDC2V4
CMPZDC2V7
CMPZDC3V0
CMPZDC3V3
CMPZDC3V6
CMPZDC3V9
CMPZDC4V3
CMPZDC4V7
CMPZDC5V1
CMPZDC5V6
CMPZDC6V2
CMPZDC6V8
CMPZDC7V5
CMPZDC8V2
CMPZDC9V1
CMPZDC10V
CMPZDC11V
CMPZDC12V
CMPZDC13V
CMPZDC15V
CMPZDC16V
CMPZDC18V
CMPZDC20V
CMPZDC22V
2.2
2.5
2.8
3.1
3.4
3.7
4.0
4.4
4.8
5.2
5.8
6.4
7.0
7.7
8.5
9.4
10.4
11.4
12.4
13.8
15.3
16.8
18.8
20.8
MAX
V
2.6
2.9
3.2
3.5
3.8
4.1
4.6
5.0
5.4
6.0
6.6
7.2
7.9
8.7
9.6
10.6
11.6
12.7
14.1
15.6
17.1
19.1
21.2
23.3
TEST
CURRENT
MAXIMUM
ZENER IMPEDANCE
MAXIMUM
REVERSE
CURRENT
IR @
μA
50
20
10
5.0
2.0
2.0
1.0
3.0
2.0
1.0
3.0
2.0
1.0
0.7
0.5
0.2
0.1
0.1
0.1
0.05
0.05
0.05
0.05
0.05
VR
V
1.0
1.0
1.0
1.0
1.0
1.0
1.0
2.0
2.0
2.0
4.0
4.0
5.0
5.0
6.0
7.0
8.0
8.0
8.0
10.5
11.2
12.6
14.0
15.4
MAXIMUM
MAXIMUM
ZENER
ZENER
VOLTAGE
CURRENT
TEMP.
COEFF.
IZM
mA
63
57
54
47
45
43
40
38
35
32
28
25
23
21
18
16
15
13
12
11
10
9.2
8.3
7.6
ΘV
Z
% / °C
-0.06
-0.06
-0.06
-0.06
-0.06
-0.06
-0.05
-0.03
0.02
0.03
0.04
0.05
0.05
0.06
0.06
0.07
0.07
0.07
0.08
0.08
0.08
0.08
0.08
0.09
CCW3
CCW4
CCW5
CCW6
CCW7
CCW8
CCW9
CCZ1
CCZ2
CCZ3
CCZ4
CCZ5
CCZ6
CCZ7
CCZ8
CCZ9
CCY1
CCY2
CCY3
CCY4
CCY5
CCY6
CCY7
CCY8
TYPE
MARKING
CODE
IZT
mA
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
ZZT @ IZT
Ω
100
100
95
95
95
90
90
80
60
40
10
15
15
15
15
20
20
25
30
30
40
45
55
55
ZZK @ IZK
Ω
mA
600
600
600
600
600
600
600
500
480
400
150
80
80
80
100
150
150
150
170
200
200
225
225
250
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
R2 (10-August 2012)
CMPZDC2V4 THRU CMPZDC47V
SURFACE MOUNT
DUAL, COMMON CATHODE
SILICON ZENER DIODES
2.4 VOLTS THRU 47 VOLTS
350mW
ELECTRICAL CHARACTERISTICS PER DIODE - Continued:
(TA=25°C) VF=0.9V MAX @ IF=10mA (for all types)
ZENER
VOLTAGE
VZ @ IZT
MIN
V
CMPZDC24V
CMPZDC27V
CMPZDC30V
CMPZDC33V
CMPZDC36V
CMPZDC39V
CMPZDC43V
CMPZDC47V
22.8
25.1
28.0
31.0
34.0
37.0
40.0
44.0
MAX
V
25.6
28.9
32.0
35.0
38.0
41.0
46.0
50.0
TEST
CURRENT
MAXIMUM
ZENER IMPEDANCE
MAXIMUM
REVERSE
CURRENT
IR @
μA
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
VR
V
16.8
18.9
21.0
23.1
25.2
27.3
30.1
32.9
MAXIMUM
MAXIMUM
ZENER
ZENER
VOLTAGE
MARKING
CURRENT
TEMP.
CODE
COEFF.
IZM
mA
7.0
6.2
5.6
5.0
4.6
4.3
3.9
3.5
ΘV
Z
% / °C
0.09
0.09
0.09
0.09
0.09
0.09
0.10
0.10
CCY9
CC10
CC11
CC12
CC13
CC14
CC15
CC16
TYPE
IZT
mA
5.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
ZZT @ IZT
Ω
70
80
80
80
90
130
150
170
ZZK @ IZK
Ω
mA
250
300
300
325
350
350
375
375
1.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
SOT-23 CASE - MECHANICAL OUTLINE
2
1
3
LEAD CODE:
1) Anode D2
2) Anode D1
3) Cathode D1, D2
MARKING CODE:
SEE MARKING CODES ON ELECTRICAL
CHARACTERISTICS TABLE
R2 (10-August 2012)
