Clock Oscillators Surface Mount Type
KC7050P-L3 Series
LVDS/ 3.3V/ 7.0×5.0mm
Features
• Miniature ceramic package
• Highly reliable with seam welding
• LVDS output
• Supply voltage V
CC
=3.3V
•
±25×10
-
6
available
How to Order
KC7050P 125.000 L 3 0 E 00
①
②
③④⑤⑥ ⑦
①
Type (7.0×5.0mm SMD)
②
Output Frequency
③
Output Type (LVDS)
④
Supply Voltage (3.3V)
⑤
Frequency Tolerance (See Table 1)
⑥
Symmetry/ INH Function
(45/ 55%, Stand-by)
⑦
Customer Special Model Suffix
(STD Specification is “00”)
Packaging (Tape & Reel 1000 pcs./ reel)
Table 1
Operating
Freq. Tol.
Note
-
6
Temperature
Code
×
10
Range (
°
C)
±
50
0
Standard specifications
±
30 0 to
+70
S
±
25
U
With only certain
frequencies
±100
F
-40
to
+85
±
50
G
RoHS Compliant
Specifications
Item
Output Frequency Range
Note1
Frequency Tolerance
Storage Temperature Range
Operating Temperature Range
Max. Supply Voltage
Supply Voltage
Current Consumption
Stand-by Current
Symmetry
Rise/ Fall Time
(20% to 80% Output Level)
Low Level Output Voltage
Note2
High Level Output Voltage
Note2
Diffrentical Output Voltage
Note2
Diffrentical Output Voltage Error
Note2
Offset Voltage
Offset Voltage Error
Output Load
Input Voltage Range
Low Level Input Voltage
High Level Input Voltage
Disable Time
Enable Time
Start-up Time
Deterministic Jitter (DJ)
1 Sigma Jitter
Peak to Peak Jitter
Symbol
fo
f
_tol
T
_stg
T
_use
—
V
CC
I
CC
I
_std
SYM
tr/ tf
V
OL
V
OH
V
OD
dV
OD
V
OS
dV
OS
RL
V
IN
V
IL
V
IH
t
_dis
t
_ena
t
_str
DJ
J
Sigma
J
PK-PK
Freq. Tol.Code: 0, S, F
Freq. Tol.Code: U, G
Standard Specifications
Extend (Option)
Conditions
Initial tolerance, Operating tem-
perature range, Rated power supply
voltage change, Load change, Aging
(1 year @25°C), Shock and vibration
Op. Temp.:
-40
to
+85°C
Op. Temp.: 0 to
+70°C/ -40
to
+85°C
Op. Temp.: 0 to
+70°C
Op. Temp.: 0 to
+70°C
Min.
50
-100
-50
-30
-25
-55
0
-40
-0.5
+2.97
+3.14
—
—
45
—
0.9
—
247
—
1.125
—
100
0
—
70% V
CC
—
—
—
—
—
—
V
CC
30% V
CC
—
200
10
10
2
4
30
Max.
190
+100
+50
+30
+25
+125
+70
+85
+5.0
+3.63
+3.46
70
30
55
0.6
—
1.6
454
50
1.375
50
Units
MHz
×10
-
6
°C
°C
V
V
mA
μA
%
ns
V
V
mV
mV
V
mV
ohm
V
V
V
ns
ms
ms
ps
ps
ps
100ohm @crossing point
100ohm
Typ. 1.1V
Typ. 1.43V
Typ. 330mV
dV
OD
=
|
V
OD1
-V
OD2|
Typ. 1.25V
dV
OS
=
|
V
OS1
-V
OS2|
LVDS Output
@Minimum operating voltage to be 0 sec.
Measured with Wavecrest SIA-3000
Note : All electrical characteristics are defined at the maximum load and operating temperature range.
Note1: Please contact us for inquiry about operating temperature range, available frequencies and other conditions.
Note2: DC characteristic
Dimensions
7.0
1.4
0.6
(Unit: mm)
Recommended Land Pattern
5.08
(Unit: mm)
2.46
#4
5.0
#3
1.17
#5
#2
#6
#1
#1
#2
#3
#4
#5
#6
Pad Connections
INH
NC
Case GND
Output
Complementary Output
V
CC
0.75
2.54
1.6
2.54
Plating: Ni+Au
Tolerance:
±0.2
INH Function
Pad1
Pad4/ Pad5 (Output)
Open
Active
"H" Level
Active
"L" Level High Z (No-Oscillation)
3.6
2.54
1.6
Note: A capacitor of value 0.01µF and 10µF
Between V
CC
and GND is recommended.
1.6
