Coaxial
50Ω
Features
High Power Amplifier
10W
480 to 900 MHz
• High power, 10 Watt
• Excellent gain flatness, ±0.7 dB
• Excellent IN/OUT matching, 20dB return loss
• High power output, +40 dBm
• High IP3, +50 dBm
• Class A amplifier
• Over-voltage protection, shuts off above 29V
• Protected against overheat, shuts off automatically
• No damage with an open or short output load under full CW output power
1
ZHL-900A-10W+
Applications
• UHF
• Cellular
• Instrumentation
• Laboratory use
Model No.
Case Style
Connectors
Price (Qty.)
ZHL-900A-10W+
ZHL-900A-10WX+
▲
DDD338
SMA
$1495.00 ea. (1-9)
$1470.00 ea. (1-9)
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
Electrical Specifications
ZHL-900A-10W+
Parameter
Frequency Range
Gain
Gain Flatness
Output Power at 1dB compression
Saturated Output Power at 3dB compression
Noise Figure
Output third order intercept point
Input VSWR
Output VSWR
DC Supply Voltage
Supply Current
1. At constant open or short load 24V nominal supply voltage
▲
ZHL-900A-10X+
▲
Max.
900
30
±1.0
Min.
480
24
+39
+41
Typ.
26
Min
480
24
+39
+41
Typ.
26
Max.
900
30
±1.0
Units
MHz
dB
dB
dBm
dBm
10.0
+50
1.3
1.3
24
2.5
3.5
10.0
+50
1.3
1.3
24
2.5
3.5
dB
dBm
:1
:1
V
A
Heat sink not included. Alternative heat sinking and heat removal must be provided by the user to limit maximum
base-plate temperature to 65°C, in order to ensure proper performance. For reference, this requires thermal resis-
tance of user’s external heat sink to be 0.25°C/W max.
Outline Drawing
Maximum Ratings
Parameter
Operating Temperature
Storage Temperature
Base Plate Temperature
DC Voltage
Input RF Power
2
(no damage)
2. At nominal output load, 24V nominal supply voltage.
Permanent damage may occur if any of these limits are exceeded.
Ratings
-20°C to 85°C
-55°C to 100°C
65°C
+25V
+25 dBm
Outline Dimensions (
inch
)
mm
A
7.00
177.80
B
3.25
82.55
C
3.13
79.50
D
E
.25 6.500
6.35 165.10
F
.38
9.65
G
2.500
63.50
H
.156
3.96
J
.88
22.35
K
.73
18.54
L
.62
15.75
M
1.13
28.70
N
2.23
56.64
P
.125
3.18
Q
R
S
T
wt
.50
6.00
2.23
8.35 grams*
12.70 152.40 56.64 212.09
1780
*510 grams without heatsink
®
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. C
M137732
ZHL-900A-10W+
ED-13362/5
MM/CP
120621
Page 1 of 2
Typical Performance Data/Curves
FREQUENCY
(MHz)
GAIN
(dB)
24V
480.00
500.00
520.00
540.00
560.00
580.00
600.00
620.00
640.00
660.00
680.00
700.00
720.00
740.00
760.00
780.00
800.00
820.00
840.00
860.00
880.00
900.00
27.81
27.65
27.47
27.28
27.11
26.95
26.81
26.71
26.61
26.57
26.55
26.57
26.63
26.73
26.90
27.08
27.30
27.52
27.73
27.88
27.95
27.91
ZHL-900A-10W+
NOISE
FIGURE
(dB)
OUT
1.12
1.11
1.13
1.14
1.15
1.14
1.12
1.10
1.07
1.07
1.08
1.09
1.11
1.12
1.12
1.10
1.08
1.06
1.07
1.12
1.19
1.25
DIRECTIVITY
(dB)
24V
29.17
30.08
30.71
31.30
33.25
33.03
33.84
34.47
36.68
37.56
39.19
38.09
37.29
38.24
40.18
40.10
41.73
37.16
40.71
37.87
37.78
41.47
VSWR
(:1)
IN
1.07
1.05
1.04
1.04
1.05
1.06
1.06
1.07
1.07
1.07
1.06
1.05
1.04
1.02
1.03
1.06
1.10
1.16
1.23
1.32
1.43
1.55
POUT at
1 dB COMPR.
(dBm)
24V
40.90
41.25
41.22
41.26
41.26
41.26
41.43
41.47
41.38
41.59
41.50
41.62
41.54
41.55
41.53
41.55
41.54
41.42
40.69
40.75
40.76
40.47
OUTPUT
IP3
(dBm)
24V
51.71
51.83
51.76
51.58
51.43
51.33
51.35
51.21
51.21
51.17
51.27
51.28
51.35
51.39
51.40
51.39
51.34
51.24
51.13
50.90
50.75
50.55
24V
11.10
11.01
10.90
10.79
10.68
10.56
10.43
10.36
10.17
10.10
9.96
9.84
9.69
9.59
9.46
9.32
9.25
9.18
9.19
9.19
9.22
9.28
30
28
GAIN (dB)
at 24V
ZHL-900A-10W+
GAIN
50
DIRECTIVITY (dB)
at 24V
ZHL-900A-10W+
DIRECTIVITY
1.8
1.6
VSWR
at 24V
ZHL-900A-10W+
VSWR
IN
OUT
45
40
35
30
25
20
450
500
550
600
650
700
750
800
850
900
26
24
22
20
450
1.4
1.2
1.0
450
500
550
600 650 700 750
FREQUENCY (MHz)
800
850
900
500
550
600
650
700
750
800
850
900
FREQUENCY (MHz)
FREQUENCY (MHz)
45
OUTPUT POWER (dBm)
ZHL-900A-10W+
OUTPUT POWER AT 1-dB COMPRESSION
at 24V
NOISE FIGURE (dB)
20
at 24V
ZHL-900A-10W+
NOISE FIGURE
60
55
IP3 (dBm)
at 24V
ZHL-900A-10W+
IP3
43
41
39
37
35
450
15
50
45
40
450
10
500
550
600 650 700 750
FREQUENCY (MHz)
800
850
900
5
450
500
550
600
650
700
750
800
850
900
500
550
600
650
700
750
800
850
900
FREQUENCY (MHz)
FREQUENCY (MHz)
