A PERFECT ALLIANCE.
ODU MEDI-SNAP
®
Miniature circular connectors with
Push-Pull locking as well as Break-Away function
PLASTIC HOUSING
METAL HOUSING
ODU MEDI-SNAP
®
ODU MINI-SNAP
®
F
ODU MINI-SNAP
®
L /K / B
ODU MINI-SNAP
®
PC
ODU MINI-MED
®
ODU AMC
®
www.odu-usa.com
ODU MEDI-SNAP
®
FEATURES
•
75% lighter than comparable metal connectors
•
Minimal requirements in terms of installation and
maintenance
•
Space-saving product design
•
High chemical resistance
•
Fully sterilizable
•
Quick mating via Push-Pull locking
•
Easy-to-release Break-Away function
APPLICATIONS
•
Medical
•
Industrial
•
Digital test and measurement
All shown connectors are according to IEC 61984:2008
(VDE 0627:2009); connectors without breaking capacity (COC).
ODU MEDI-SNAP® is UL-approved under File E110586.
All dimensions are in mm.
Some figures are for illustrative purposes only.
Subject to change without notice. Errors and omissions excepted.
We reserve the right to change our products and their technical
specifications at any time in the interest of technical improvement.
This publication supersedes all prior publications.
This publication is also available as a PDF file that can be
downloaded from
www.odu-usa.com
Issue: 2019-01
TABLE OF CONTENTS
Clickable page
numbers
THE ODU CORPORATE GROUP
PRODUCT INFORMATION
The complete series of ODU connectors at a glance
The circular connector MEDI-SNAP® with plastic and metal housing
Functional principle of the Push-Pull locking
Functional principle of the Break-Away function
Facts & figures
4
10
12
13
14
15
16
CONFIGURATION GUIDELINE
Correct configuring – step by step
18
20
ODU MEDI-SNAP
®
WITH PLASTIC HOUSING
SIZE 1
Summary
Styles
Codings
Contact inserts and PCB layouts
Cable collet system
Accessories
24
26
28
39
40
46
47
SIZE 2
Summary
Styles
Codings
Contact inserts and PCB layouts
Cable collet system
Accessories
56
58
62
63
68
69
ODU MEDI-SNAP
®
WITH METAL HOUSING
SIZE 1
Summary
Styles
Codings
Contact inserts and PCB layouts
Cable collet system
Accessories
74
76
78
82
83
88
89
TOOLS, CRIMP INFORMATION, PROCESSING INSTRUCTIONS, ACCESSORIES
Crimping tools /assembly tools
Spanner wrench
Wrench for device front nuts
Removal tools for crimp-clip-contacts
94
96
98
98
99
TECHNICAL INFORMATION
International protection classes acc. IEC 60529:2013 (VDE 0470-1:2014)
Housing materials and insulator materials
Termination technologies
Conversions /AWG
Current load of turned contacts
Operating voltage
Autoclaving
Technical terms
101
102
104
105
106
107
108
109
110
For assembly instructions, please refer to our website: www.odu-usa.com/downloads/assembly-instructions
3
A PERFECT
ALLIANCE.
CREATING CONNECTIONS, BUILDING ALLIANCES, COLLABO-
RATING INTO THE FUTURE:
WHETHER TWO TECHNICAL COM-
PONENTS COME TOGETHER TO FORM A UNIT OR PEOPLE COME
TOGETHER TO STRIVE FOR GREAT RESULTS – THE KEY IS TO
ASPIRE IN ACHIEVING SUPERB RESULTS. THIS GOAL DRIVES OUR
WORK.
PERFECT CONNECTIONS THAT INSPIRE AND DELIVER
ON THE PROMISES.
ODU WORLDWIDE
ODU Scandinavia AB
ODU-USA, Inc.
ODU North American Logistics
ODU Denmark ApS
ODU GmbH & Co. KG
Headquarters
ODU (Shanghai)
International Trading Co., Ltd.
ODU (Shanghai)
Connectors Manufacturing Co.Ltd
ODU Japan K.K.
ODU Mexico
Manufacturing S.R.L. de C.V.
ODU Romania Manufacturing S.R.L.
ODU Italia S.R.L.
ODU France SARL
ODU-UK Ltd.
ODU GROUP OVERVIEW
• More than 75 years of experience in connector technology
• A turnover of 170 million Euro
• Over 1,900 employees worldwide
• 9 sales subsidiaries in China, Denmark, France, Germany,
Italy, Japan, Sweden, the UK and the US as well as
5 production and logistics sites
• All technologies under one roof: Design and development,
machine tool and special machine construction, injection,
stamping, turning, surface technology, assembly and
cable assembly
As of February 2018
CERTIFIED QUALITY
• DIN EN ISO 9001
• IATF 16949
• DIN EN ISO 14001
• ISO 13485
• Wide range of UL, CSA, VG and DVA licenses
• UL certified cable assembly
For a complete list of our certifications, please visit our website.
