H5TQ1G63AFPR-G7C datasheet, PDF

Datasheet> All Categories > storage> storage> H5TQ1G63AFPR-G7C

H5TQ1G63AFPR-G7C: DescriptionDDR DRAM, 64MX16, 0.3ns, CMOS, PBGA96, HALOGEN FREE, FPBGA-96; Categorystorage storage; File Size4MB，77 Pages; ManufacturerSK Hynix; Websitehttp://www.hynix.com/eng/

Download Datasheet Parametric Compare View All

H5TQ1G63AFPR-G7C Overview

DDR DRAM, 64MX16, 0.3ns, CMOS, PBGA96, HALOGEN FREE, FPBGA-96

H5TQ1G63AFPR-G7C Parametric

Parameter Name	Attribute value
Parts packaging code	BGA
package instruction	TFBGA,
Contacts	96
Reach Compliance Code	unknown
ECCN code	EAR99
access mode	MULTI BANK PAGE BURST
Maximum access time	0.3 ns
Other features	AUTO/SELF REFRESH
JESD-30 code	R-PBGA-B96
length	13 mm
memory density	1073741824 bit
Memory IC Type	DDR DRAM
memory width	16
Number of functions	1
Number of ports	1
Number of terminals	96
word count	67108864 words
character code	64000000
Operating mode	SYNCHRONOUS
Maximum operating temperature	85 °C
Minimum operating temperature
organize	64MX16
Package body material	PLASTIC/EPOXY
encapsulated code	TFBGA
Package shape	RECTANGULAR
Package form	GRID ARRAY, THIN PROFILE, FINE PITCH
Certification status	Not Qualified
Maximum seat height	1.2 mm
self refresh	YES
Maximum supply voltage (Vsup)	1.575 V
Minimum supply voltage (Vsup)	1.425 V
Nominal supply voltage (Vsup)	1.5 V
surface mount	YES
technology	CMOS
Temperature level	OTHER
Terminal form	BALL
Terminal pitch	0.8 mm
Terminal location	BOTTOM
width	8 mm
Base Number Matches	1

Preview

Download Datasheet

View All

H5TQ1G43AFP(R)-xxC

H5TQ1G83AFP(R)-xxC

H5TQ1G63AFP(R)-xxC

1Gb DDR3 SDRAM

H5TQ1G43AFP(R)-xxC

H5TQ1G83AFP(R)-xxC

H5TQ1G63AFP(R)-xxC

** Contents are subject to change at any time without notice.

Rev. 0.4 / January 2009

This document is a general product description and is subject to change without notice. Hynix semiconductor does not assume any

responsibility for use of circuits described. No patent licenses are implied.

H5TQ1G63AFPR-G7C Related Products

	H5TQ1G63AFPR-G7C	H5TQ1G83AFPR-S6C	H5TQ1G83AFPR-G7C	H5TQ1G63AFPR-S6C	H5TQ1G63AFPR-H9C	H5TQ1G43AFPR-G7C	H5TQ1G43AFPR-S6C	H5TQ1G43AFPR-H9C	H5TQ1G83AFPR-H9C
Description	DDR DRAM, 64MX16, 0.3ns, CMOS, PBGA96, HALOGEN FREE, FPBGA-96	DDR DRAM, 128MX8, 0.4ns, CMOS, PBGA78, HALOGEN FREE, FPBGA-78	DDR DRAM, 128MX8, 0.3ns, CMOS, PBGA78, HALOGEN FREE, FPBGA-78	DDR DRAM, 64MX16, 0.4ns, CMOS, PBGA96, HALOGEN FREE, FPBGA-96	DDR DRAM, 64MX16, 0.255ns, CMOS, PBGA96, HALOGEN FREE, FPBGA-96	DDR DRAM, 256MX4, 0.3ns, CMOS, PBGA78, HALOGEN FREE, FPBGA-78	DDR DRAM, 256MX4, 0.4ns, CMOS, PBGA78, HALOGEN FREE, FPBGA-78	DDR DRAM, 256MX4, 0.255ns, CMOS, PBGA78, HALOGEN FREE, FPBGA-78	DDR DRAM, 128MX8, 0.255ns, CMOS, PBGA78, HALOGEN FREE, FPBGA-78
Parts packaging code	BGA	BGA	BGA	BGA	BGA	BGA	BGA	BGA	BGA
package instruction	TFBGA,	TFBGA,	TFBGA,	TFBGA,	TFBGA,	TFBGA,	TFBGA,	TFBGA,	TFBGA,
Contacts	96	78	78	96	96	78	78	78	78
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknow
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
access mode	MULTI BANK PAGE BURST	MULTI BANK PAGE BURST	MULTI BANK PAGE BURST	MULTI BANK PAGE BURST	MULTI BANK PAGE BURST	MULTI BANK PAGE BURST	MULTI BANK PAGE BURST	MULTI BANK PAGE BURST	MULTI BANK PAGE BURST
Maximum access time	0.3 ns	0.4 ns	0.3 ns	0.4 ns	0.255 ns	0.3 ns	0.4 ns	0.255 ns	0.255 ns
Other features	AUTO/SELF REFRESH	AUTO/SELF REFRESH	AUTO/SELF REFRESH	AUTO/SELF REFRESH	AUTO/SELF REFRESH	AUTO/SELF REFRESH	AUTO/SELF REFRESH	AUTO/SELF REFRESH	AUTO/SELF REFRESH
JESD-30 code	R-PBGA-B96	R-PBGA-B78	R-PBGA-B78	R-PBGA-B96	R-PBGA-B96	R-PBGA-B78	R-PBGA-B78	R-PBGA-B78	R-PBGA-B78
length	13 mm	11.5 mm	11.5 mm	13 mm	13 mm	11.5 mm	11.5 mm	11.5 mm	11.5 mm
memory density	1073741824 bit	1073741824 bit	1073741824 bit	1073741824 bit	1073741824 bit	1073741824 bit	1073741824 bit	1073741824 bit	1073741824 bi
Memory IC Type	DDR DRAM	DDR DRAM	DDR DRAM	DDR DRAM	DDR DRAM	DDR DRAM	DDR DRAM	DDR DRAM	DDR DRAM
memory width	16	8	8	16	16	4	4	4	8
Number of functions	1	1	1	1	1	1	1	1	1
Number of ports	1	1	1	1	1	1	1	1	1
Number of terminals	96	78	78	96	96	78	78	78	78
word count	67108864 words	134217728 words	134217728 words	67108864 words	67108864 words	268435456 words	268435456 words	268435456 words	134217728 words
character code	64000000	128000000	128000000	64000000	64000000	256000000	256000000	256000000	128000000
Operating mode	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
organize	64MX16	128MX8	128MX8	64MX16	64MX16	256MX4	256MX4	256MX4	128MX8
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	TFBGA	TFBGA	TFBGA	TFBGA	TFBGA	TFBGA	TFBGA	TFBGA	TFBGA
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	GRID ARRAY, THIN PROFILE, FINE PITCH	GRID ARRAY, THIN PROFILE, FINE PITCH	GRID ARRAY, THIN PROFILE, FINE PITCH	GRID ARRAY, THIN PROFILE, FINE PITCH	GRID ARRAY, THIN PROFILE, FINE PITCH	GRID ARRAY, THIN PROFILE, FINE PITCH	GRID ARRAY, THIN PROFILE, FINE PITCH	GRID ARRAY, THIN PROFILE, FINE PITCH	GRID ARRAY, THIN PROFILE, FINE PITCH
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	1.2 mm	1.2 mm	1.2 mm	1.2 mm	1.2 mm	1.2 mm	1.2 mm	1.2 mm	1.2 mm
self refresh	YES	YES	YES	YES	YES	YES	YES	YES	YES
Maximum supply voltage (Vsup)	1.575 V	1.575 V	1.575 V	1.575 V	1.575 V	1.575 V	1.575 V	1.575 V	1.575 V
Minimum supply voltage (Vsup)	1.425 V	1.425 V	1.425 V	1.425 V	1.425 V	1.425 V	1.425 V	1.425 V	1.425 V
Nominal supply voltage (Vsup)	1.5 V	1.5 V	1.5 V	1.5 V	1.5 V	1.5 V	1.5 V	1.5 V	1.5 V
surface mount	YES	YES	YES	YES	YES	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	OTHER	OTHER	OTHER	OTHER	OTHER	OTHER	OTHER	OTHER	OTHER
Terminal form	BALL	BALL	BALL	BALL	BALL	BALL	BALL	BALL	BALL
Terminal pitch	0.8 mm	0.8 mm	0.8 mm	0.8 mm	0.8 mm	0.8 mm	0.8 mm	0.8 mm	0.8 mm
Terminal location	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM
width	8 mm	8 mm	8 mm	8 mm	8 mm	8 mm	8 mm	8 mm	8 mm
Maker	-	SK Hynix	SK Hynix	SK Hynix	SK Hynix	SK Hynix	SK Hynix	SK Hynix	SK Hynix
