DP72L2L-1.00HZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> filter> DP72L2L-1.00HZ

DP72L2L-1.00HZ: DescriptionActive Filter, 1 Func, Bessel, Lowpass, PDIP16,; CategoryAnalog mixed-signal IC filter; File Size468KB，6 Pages; ManufacturerFrequency Devices

Download Datasheet Parametric Compare View All

DP72L2L-1.00HZ Overview

Active Filter, 1 Func, Bessel, Lowpass, PDIP16,

DP72L2L-1.00HZ Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
package instruction	DIP, DIP5/16,.3
Reach Compliance Code	unknown
Other features	LG-MAX, WD-MAX
JESD-30 code	R-PDIP-T5
length	22.352 mm
Maximum negative supply voltage (Vsup)	-18 V
Negative supply voltage minimum (Vsup)	-5 V
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	1
Number of terminals	5
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Encapsulate equivalent code	DIP5/16,.3
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
Maximum seat height	9.525 mm
Maximum supply current (Isup)	1.5 mA
Maximum supply voltage (Vsup)	18 V
Minimum supply voltage (Vsup)	5 V
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Temperature level	COMMERCIAL
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	11.684 mm
Base Number Matches	1

Preview

Download Datasheet

View All

D72 & DP72 Series

1.0 Hz to 100 kHz

Fixed Frequency

Description

The D72 and DP72 Series of low-power, fixed-

frequency, linear active filters are high performance,

2-pole filters in a compact package. These

Butterworth and Bessel low-pass and Butterworth

high-pass filters (D72 only) combine linear active

filter design with the space savings of a 16-pin dual

in-line package (DIP). Each model comes factory

tuned to a user-specified corner frequency between

1 Hz and 100 kHz (DP72, 1 Hz to 5kHz). These fully

self-contained units require no external components

or adjustments and operate with dynamic input

voltage range from non-critical ±5V to ±18V power

supplies.

Features/Benefits:

• Low cost solution for low frequency signal

conditioning

• Compact DIP design minimizes board space

requirements

• Plug-in ready-to-use, reducing engineering design

and manufacturing time

• Factory tuned, no external clocks or adjustments

needed saving time and labor of other discrete

assembly solutions

• Low harmonic distortion and wide signal-to-noise

ratio to 12 bit resolution

Applications

• Anti-alias filtering

• Vibration & shock analysis

• Automatic test equipment

• Aerospace, navigation and sonar

• Communication systems

• Medical electronics

• Sound and vibration testing

• Noise elimination

• Process control

Available

D72L2B

DP72L2B

D72L2L

DP72L2L

Low-Pass Models:

. . . . . . . . . . . . . . . .

2-pole Butterworth . . . . . . . . . . . . . . .2

2-pole Butterworth (Low Power) . . . . .2

2-pole Bessel . . . . . . . . . . . . . . . . . . .2

2-pole Bessel (Low Power) . . . . . . . .2

16 Pin DIP

2-Pole Filters

Available High-Pass Models:

D72H2B

2-pole Butterworth . . . . . . . . . . . . . . .2

General Specifications:

Pin-out/package data & ordering information . . . .3

25 Locust St, Haverhill, Massachusetts 01830 • Tel: 800/252-7074, 978/374-0761 • FAX: 978/521-1839

e-mail: sales@freqdev.com • Web Address: http://www.freqdev.com

DP72L2L-1.00HZ Related Products

	DP72L2L-1.00HZ	D72H2B-1.00HZ	D72L2L-1.00HZ	DP72L2B-1.00HZ	DP72L2L-5.00KHZ
Description	Active Filter, 1 Func, Bessel, Lowpass, PDIP16,	Active Filter, 1 Func, Butterworth, Highpass, PDIP16,	Active Filter, 1 Func, Bessel, Lowpass, PDIP16,	Active Filter, 1 Func, Butterworth, Lowpass, PDIP16,	Active Filter, 1 Func, Bessel, Lowpass, PDIP16,
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible
package instruction	DIP, DIP5/16,.3	DIP, DIP5/16,.3	DIP, DIP5/16,.3	DIP, DIP5/16,.3	DIP, DIP5/16,.3
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown
Other features	LG-MAX, WD-MAX	LG-MAX, WD-MAX	LG-MAX, WD-MAX	LG-MAX, WD-MAX	LG-MAX, WD-MAX
JESD-30 code	R-PDIP-T5	R-PDIP-T5	R-PDIP-T5	R-PDIP-T5	R-PDIP-T5
length	22.352 mm	22.352 mm	22.352 mm	22.352 mm	22.352 mm
Maximum negative supply voltage (Vsup)	-18 V	-18 V	-18 V	-18 V	-18 V
Negative supply voltage minimum (Vsup)	-5 V	-5 V	-5 V	-5 V	-5 V
Nominal Negative Supply Voltage (Vsup)	-15 V	-15 V	-15 V	-15 V	-15 V
Number of functions	1	1	1	1	1
Number of terminals	5	5	5	5	5
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C	70 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	DIP	DIP	DIP	DIP	DIP
Encapsulate equivalent code	DIP5/16,.3	DIP5/16,.3	DIP5/16,.3	DIP5/16,.3	DIP5/16,.3
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	9.525 mm	9.525 mm	9.525 mm	9.525 mm	9.525 mm
Maximum supply current (Isup)	1.5 mA	5 mA	5 mA	1.5 mA	1.5 mA
Maximum supply voltage (Vsup)	18 V	18 V	18 V	18 V	18 V
Minimum supply voltage (Vsup)	5 V	5 V	5 V	5 V	5 V
Nominal supply voltage (Vsup)	15 V	15 V	15 V	15 V	15 V
surface mount	NO	NO	NO	NO	NO
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal form	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL
width	11.684 mm	11.684 mm	11.684 mm	11.684 mm	11.684 mm
Base Number Matches	1	1	1	1	1
