FILTERS
TECHNOLOGY OF TOMORROW
TWO TERMINAL
MULTILAYER FERRITE
POWER BEADS
CZP (MCP)
STRUCTURE
1
2
3
4
5
Solder plating
Diffusion barrier (Ni)
Silver metallisation
Ferrite
Electrode
IDENTIFICATION
TYPE
CZP
COATING COLOR
Black
MARKING
None
Products with Pb-free terminations
meet RoHS requirements
TYPE DESIGNATION (HOW TO ORDER)
Old Part No.
Specifications given herein may be changed at any time without prior notice.
Please confirm technical specifications before you order and/or use.
MCP
CZP
PRODUCT CODE
0603
1J
SIZE
1J = 0603
2A = 0805
2B = 1206
F
F
PERMEABILITY
CODE
F, P
M
T
TERMINATION
SURFACE MATERIAL
T: Sn
L: Sn/Pb
TE
TE
300
300
NOMINAL
IMPEDANCE
3 digits
New Part No.
(Pb-free)
M
IMPEDANCE
TOLERANCE
P(±25%)
M(±20%)
IMPEDANCE
TOLERANCE
TAPING *
TE: 7’’ embossed taping
*Please see “PACKAGING”
FEATURES
■
■
■
■
■
■
Designed to reduce noise in a wide frequency range
Large permissible DC current
Monolithic structure for closed magnetic path and high reliability
Anti-leaching nickel barrier terminations
Wide range of electrical properties; magnetically shielded
Suitable as noise suppressor in computers and peripherals,
telecommunication, data communication and in consumer electronics
■
Operating temperature range: –55° C … +125° C
■
Suitable for reflow and wave soldering
DIMENSIONS (mm)
SIZE
0603 (1J)
0805 (2A)
1206 (2B)
L
1.60 ± 0.15
2.00 ± 0.20
3.20 ± 0.20
W
0.80 ± 0.15
1.25 ± 0.20
1.60 ± 0.20
t
0.80 ± 0.15
0.90 ± 0.20
1.10 ± 0.20
c
0.36 ± 0.15
0.51 ± 0.25
0.51 ± 0.25
RATING
TYPE
CZP 1J F T TE 5R0 P
CZP 1J F T TE 300 P
CZP 1J F T TE 600 P
CZP 1J F T TE 121 P
CZP 1J F T TE 301 P
CZP 2A F T TE 7R0 P
CZP 2A F T TE 100 P
CZP 2A F T TE 110 P
CZP 2A F T TE 150 P
CZP 2A F T TE 220 P
CZP 2A F T TE 300 P
CZP 2A F T TE 400 P
CZP 2A F T TE 450 P
CZP 2A F T TE 600 P
CZP 2A F T TE 800 P
CZP 2A F T TE 201 P
CZP 2A F T TE 221 P
CZP 2A F T TE 301 P
CZP 2A F T TE 601 P
CZP 2A F T TE 102 P
IMPEDANCE
at 100 MHz*
5
Ω
30
Ω
60
Ω
120
Ω
300
Ω
7
Ω
10
Ω
11
Ω
15
Ω
22
Ω
30
Ω
40
Ω
45
Ω
60
Ω
80
Ω
200
Ω
220
Ω
300
Ω
600
Ω
1000
Ω
DC RESISTANCE
(MAX.)**
0.04
Ω
0.06
Ω
0.1
Ω
0.1
Ω
0.1
Ω
0.02
Ω
0.02
Ω
0.025
Ω
0.025
Ω
0.025
Ω
0.015
Ω
0.03
Ω
0.03
Ω
0.025
Ω
0.1
Ω
0.15
Ω
0.05
Ω
0.15
Ω
0.2
Ω
0.2
Ω
ALLOWABLE
DC CURRENT
(MAX.)
1.000 mA
3.000 mA
500 mA
2.000 mA
2.000 mA
3.000 mA
3.000 mA
3.000 mA
3.000 mA
3.000 mA
3.000 mA
2.000 mA
2.000 mA
3.000 mA
1.000 mA
1.000 mA
2.000 mA
1.000 mA
1.000 mA
1.000 mA
CZP
CZP
CZP
CZP
CZP
CZP
CZP
CZP
CZP
CZP
CZP
CZP
CZP
CZP
CZP
CZP
TYPE
2B F T TE 190 P
2B F T TE 260 P
2B F T TE 300 P
2B F T TE 310 P
2B F T TE 500 P
2B F T TE 650 P
2B F T TE 700 P
2B F T TE 800 P
2B F T TE 900 P
2B F T TE 101 P
2B F T TE 121 P
2B F T TE 601 P
2B P T TE 700 P
2B P T TE 101 P
2B P T TE 121 P
2B P T TE 601 P
IMPEDANCE
at 100 MHz*
19
Ω
26
Ω
30
Ω
31
Ω
50
Ω
65
Ω
70
Ω
80
Ω
90
Ω
100
Ω
120
Ω
600
Ω
70
Ω
100
Ω
120
Ω
600
Ω
DC RESISTANCE
(MAX.)**
0.02
Ω
0.02
Ω
0.02
Ω
0.02
Ω
0.025
Ω
0.03
Ω
0.03
Ω
0.03
Ω
0.1
Ω
0.1
Ω
0.1
Ω
0.2
Ω
0.2
Ω
0.03
Ω
0.04
Ω
0.1
Ω
ALLOWABLE
DC CURRENT
(MAX.)
3.000 mA
3.000 mA
3.000 mA
3.000 mA
3.000 mA
2.000 mA
2.000 mA
2.000 mA
1.000 mA
1.000 mA
1.000 mA
1.000 mA
3.000 mA
3.000 mA
3.000 mA
1.500 mA
* Impedance test method: HP 4291A
** DCR test method: Keithley 580
EUROPE GmbH • Kaddenbusch 6 • D-25578 Dägeling / ITZEHOE • PHONE: +49 (0) 48 21 / 89 89-0 • FAX: +49 (0) 48 21/ 89 89 89 • Internet: www.koaeurope.de
89
45/04
