431KD14JX: DescriptionRESISTOR, VOLTAGE DEPENDENT, 350V, 155J, THROUGH HOLE MOUNT, RADIAL LEADED; CategoryPassive components The resistor; File Size118KB，6 Pages; ManufacturerMicro Commercial Components (MCC)

Download Datasheet Parametric Compare View All

431KD14JX Overview

RESISTOR, VOLTAGE DEPENDENT, 350V, 155J, THROUGH HOLE MOUNT, RADIAL LEADED

431KD14JX Parametric

Parameter Name	Attribute value
Objectid	1743979308
package instruction	RADIAL LEADED
Reach Compliance Code	unknown
ECCN code	EAR99
Circuit maximum DC voltage	350 V
Circuit RMS maximum voltage	275 V
Maximum energy absorption capacity	155 J
Installation features	THROUGH HOLE MOUNT
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package shape	DISK PACKAGE
method of packing	BULK; TR
Rated temperature	85 °C
Resistor type	VARISTOR
surface mount	NO
Terminal location	RADIAL
Terminal shape	WIRE

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

omponents

20736 Marilla Street Chatsworth

!"#

$ % !"#

182KD14JX*

thru

180LD14JX*

11 to 1000 Volts

Varistor

5.2 to 510 Joule

Features

•

High Surge, High Energy

Designed to be Operated Continuously Across AC Power Lines

No Derating Up to 85 Ambient

Available in Tape and Reel or Bulk Pack

UL Recognized File # E306895(UL1449) and E306942(UL1414)

Maximum Ratings

•

Operating Ambient Temperature Range: -55 to +85

Storage Temperature Range: -55 to +125

Temperature Coefficient ( V) of Clamping Voltage (V

) at

Specified Test Current:<0.05%/

Varistor voltage temperature coefficient:

Vb at 25 - Vb at 85

Vb at 25

x(100/

)

Kink Lead

120

100

L: 20mm Min.

DIMENSIONS

Unit: mm

Size D max

H max

C/I/Y

19.5

D±

0.05

All

0.6

0.8

E±

1.0

All

7.5

Lead

05D

07D

-55

100

120

140

160

All

7.5

12.5

16.5

10D

14D

20D

AMBIENT TEMPERATURE (°C)

PERCENT OF RATED VALUE

CURRENT, ENERGY AND POWER DERATING

CURVE

Note :

'X' can be S, C, I or Y .

'S'

'C'

'I'

'Y'

denotes

straight lead

out crimped lead

inner crimped lead

kink lead

www.mccsemi.com

Revision: 2

1 of 6

2006/09/09

431KD14JX Related Products

	431KD14JX	361KD14JX	101KD14JX	201KD14JX	241KD14JX
Description	RESISTOR, VOLTAGE DEPENDENT, 350V, 155J, THROUGH HOLE MOUNT, RADIAL LEADED	RESISTOR, VOLTAGE DEPENDENT, 300V, 130J, THROUGH HOLE MOUNT, RADIAL LEADED	RESISTOR, VOLTAGE DEPENDENT, 85V, 36J, THROUGH HOLE MOUNT, RADIAL LEADED	RESISTOR, VOLTAGE DEPENDENT, 170V, 70J, THROUGH HOLE MOUNT, RADIAL LEADED	RESISTOR, VOLTAGE DEPENDENT, 200V, 84J, THROUGH HOLE MOUNT, RADIAL LEADED
Objectid	1743979308	1743979305	1743979288	1743979296	1743979299
package instruction	RADIAL LEADED	RADIAL LEADED	RADIAL LEADED	RADIAL LEADED	RADIAL LEADED
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99
Circuit maximum DC voltage	350 V	300 V	85 V	170 V	200 V
Circuit RMS maximum voltage	275 V	230 V	60 V	130 V	150 V
Maximum energy absorption capacity	155 J	130 J	36 J	70 J	84 J
Installation features	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT
Number of terminals	2	2	2	2	2
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Package shape	DISK PACKAGE	DISK PACKAGE	DISK PACKAGE	DISK PACKAGE	DISK PACKAGE
method of packing	BULK; TR	BULK; TR	BULK; TR	BULK; TR	BULK; TR
Rated temperature	85 °C	85 °C	85 °C	85 °C	85 °C
Resistor type	VARISTOR	VARISTOR	VARISTOR	VARISTOR	VARISTOR
surface mount	NO	NO	NO	NO	NO
Terminal location	RADIAL	RADIAL	RADIAL	RADIAL	RADIAL
Terminal shape	WIRE	WIRE	WIRE	WIRE	WIRE
