SK24
Vishay Aztronic
High Current Toroidal Inductors,
EMI/RFI Noise Suppression, Switching Power Supplies
and Output Chokes
FEATURES
•
SK series inductors have a copper winding on a toroid
•
Available with a bare construction or in a case
•
Main uses are power supply, filtering or dc-to-dc
converters with frequencies up to 300 kHz
DIMENSIONS
in millimeters
SK24 N
24
SK24 E
(10 µH to 100 µH)
24
1
SK24 V
12.5
2
18
4
28
3
12.5
1
2
SK24 H
20
3
23
4
28
11
15
11
15
24
26
11
30
17.5
3.5
3.5
Ød
0.7 x 0.7
3.5
0.7 x 0.7
10
Ød
ELECTRICAL SPECIFICATIONS
Tolerance
Max. Operating Frequency
Maximum Voltage
± 20 %
300 kHz
250 V
RMS
MECHANICAL SPECIFICATIONS
Magnetic Circuit
Terminals
toroid
wire N, S and E versions
pins: V and H versions
PACKAGING
50 pieces in box
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature Range
- 40 °C + 125 °C
MARKING (V AND H VERSIONS)
Print marked:
manufacturer, model, style, inductance value, nominal
current
www.vishay.com
33
For technical questions, contact: sfer@vishay.com
Document Number: 59021
Revision: 01-Oct-07
SK24
High Current Toroidal Inductors,
Vishay Aztronic
EMI/RFI Noise Suppression, Switching Power Supplies
and Output Chokes
ORDERING INFORMATION
SK
MODEL
24
STYLE
S
VERSION
47 µH
INDUCTANCE VALUE
NO LOAD
e2
LEAD FINISH
e2: SnCu
SAP PART NUMBERING GUIDELINES
S
K
2
4
S
VERSION
4
7
0
M
B
2
5
MODEL
STYLE
INDUCTANCE
VALUE
TOL.
PACKAGING
CODE
SPECIAL
(IF APPLICABLE)
See the end of this data book for conversion tables
INDUCTANCE VALUE VERSUS CURRENT
L
with
no load
L at
nominal
current
0
I nominal
I
MAX.
A
6
4
3
2
1.5
1
0.7
L
WITH
NO LOAD
µH
10
22
47
100
220
470
1000
L MIN.
AT NOMINAL
CURRENT
µH
7
15
33
70
154
330
700
DCR
MAX.
mΩ
8
21
39
91
166
376
871
Ø D MAX.
(WIRE DIAMETER)
N - S - E VERSIONS
mm
1.2
0.9
0.8
0.7
0.6
0.5
0.4
On request: other values or pin configuration.
Document Number: 59021
Revision: 01-Oct-07
For technical questions, contact: sfer@vishay.com
www.vishay.com
34
