FEATURES
Low ESR
-
High Ripple Current
–
Multiple case sizes
APPLICATIONS
Filtering
–
Bypass
–
Coupling
–
Blocking
-55°C to +105°C
+20% at 120 Hz, 20°C
6.3
7.9
6.3
.26
10
13
10
.22
16
20
16
.18
25
32
25
.16
35
44
50
63
Operating Temperature Range
Capacitance Tolerance
WVDC
Surge voltage
SVDC
WVDC
Tan
δ
Dissipation Factor
Leakage current
Low temperature
stability
Impedance ratio
(120 Hz)
35
50
.14
.12
Add .02 for every 1000uF above 1000uF
1 Minute
.03CV
6.3
6
10
6
16
4
25
4
35
4
50
3
WVDC
-55°C to +20°C
Load Life
Shelf Life
3000 hours at 105°C with rated WVDC and ripple current applied
(2000 hrs for D<6.3)
Capacitance change
<20% of initial measured value
Dissipation factor
<200% of maximum specified value
Leakage current
<100% of maximum specified value
1000 hours at 105°C with no voltage applied
Capacitance change
<20% initial measured value
Dissipation factor
<200% of maximum specified value
Leakage current
<100% of maximum specified value
Frequency (Hz)
Capacitance
C<4.7
4.7<C<33
33<C<100
100<C<270
270<C<1000
C>1000
50
.3
.38
.48
.6
.68
.82
120
.43
.51
.6
.72
.83
.91
300
.7
.62
.71
.8
.9
.98
1k
.54
.76
.85
.91
.96
.98
10k
.83
.87
.9
.95
1.0
1.0
100k
1.0
1.0
1.0
1.0
1.0
1.0
+105
1.0
1.0
1.0
1.0
1.0
1.0
Temperature (°C)
+85
1.73
1.73
1.73
1.73
1.73
1.73
+65
2.19
2.19
2.19
2.19
2.19
2.19
+50
2.4
2.4
2.4
2.4
2.4
2.4
Ripple Current Multipliers
D
5
6.3
8
S
2.0
2.5
3.5
d
0.5
0.5
0.6
L<16mm, L
1
=L+1.5mm Max.
L>16mm, L
1
=L+2mm Max.
D
1
=D+0.5mm Max.
S
1
=S+0.5 mm
10
5.0
0.6
12.5
5.0
0.6
16
7.5
0.8
18
7.5
0.8
mm
