SMD-Type
SSB Coils
• Tape and Reel Dimensions (see page 34 to 35)
• SSB15 Series (SSB 15-)
Model
Inductance
L(µH)
at 10 kHz, 1mA
Rdc
(m )
max.
Rated current
(A)
∆T=20˚C
∆T=40˚C
Current
(Ref.)
(A)
15-1R0
15-1R5
15-2R2
15-3R3
15-4R7
15-6R8
15-100
15-150
15-220
15-330
15-470
15-680
15-101
15-151
15-221
15-331
15-471
15-681
15-102
1.0±20%
1.5±20%
2.2±20%
3.3±20%
4.7±20%
6.8±20%
10±20%
15±20%
22±20%
33±20%
47±10%
68±10%
100±10%
150±10%
220±10%
330±10%
470±10%
680±10%
1000±10%
10
10
20
20
20
30
40
60
80
110
180
220
320
430
600
960
1400
2000
3000
10.00
8.80
6.40
5.90
5.00
4.30
3.40
2.70
2.20
1.80
1.40
1.20
1.00
0.87
0.71
0.55
0.45
0.36
0.29
14.00
12.30
8.90
8.20
7.00
6.00
4.70
3.70
3.00
2.50
1.90
1.60
1.40
1.20
0.99
0.77
0.63
0.50
0.40
L change rate 10%
24.50
19.60
14.00
12.20
10.80
8.90
7.00
5.70
4.90
4.00
3.20
2.70
2.20
1.80
1.40
1.20
1.00
0.85
0.71
•
SSB14 Series
(
SSB 14-
)
Model
Inductance
L(µH)
at 10 kHz, 1mA
Rdc
(m )
max.
Rated current
(A)
∆T=20˚C
∆T=40˚C
Current
(Ref.)
(A)
14-1R0
14-1R5
14-2R2
14-3R3
14-4R7
14-6R8
14-100
14-150
14-220
14-330
14-470
14-680
14-101
14-151
14-221
14-331
14-471
14-681
14-102
1.0±20%
1.5±20%
2.2±20%
3.3±20%
4.7±20%
6.8±20%
10±20%
15±20%
22±20%
33±20%
47±10%
68±10%
100±10%
150±10%
220±10%
330±10%
470±10%
680±10%
1000±10%
10
20
20
30
30
40
60
100
120
170
210
300
480
710
1000
1500
2300
3400
4400
7.00
6.10
5.10
4.10
3.80
3.00
2.40
1.80
1.60
1.30
1.10
0.97
0.75
0.60
0.51
0.40
0.32
0.26
0.23
9.80
8.50
7.10
5.70
5.30
4.20
3.30
2.50
2.20
1.80
1.50
1.30
1.00
0.84
0.71
0.56
0.44
0.36
0.32
L change rate 10%
17.50
14.00
11.60
10.00
8.70
7.00
5.80
4.60
3.80
3.10
2.60
2.10
1.80
1.40
1.20
1.00
0.86
0.72
0.58
Choke Coils VOL.02
28
SMD-Type
• SSB84
Series (
SSB 84-
)
Model
Inductance
L(µH)
at 10 kHz, 1mA
R
dc
(m )
max.
Rated current
(A)
∆T=20˚C
∆T=40˚C
Current
(Ref.)
(A)
84-1R0
84-1R5
84-2R2
84-3R3
84-4R7
84-6R8
84-100
84-150
84-220
84-330
84-470
84-680
84-101
84-151
84-221
84-331
84-471
84-681
84-102
1.0±20%
1.5±20%
2.2±20%
3.3±20%
4.7±20%
6.8±20%
10±20%
15±20%
22±20%
33±20%
47±10%
68±10%
100±10%
150±10%
220±10%
330±10%
470±10%
680±10%
1000±10%
40
40
50
50
60
80
100
110
160
200
300
410
570
1100
1450
2000
3300
4100
5600
2.30
2.20
2.00
1.90
1.70
1.60
1.40
1.20
1.20
1.00
0.75
0.70
0.60
0.40
0.35
0.30
0.20
0.20
0.18
3.20
3.00
2.80
2.60
2.30
2.20
1.90
1.60
1.60
1.40
1.00
0.98
0.84
0.56
0.49
0.42
0.28
0.28
0.25
L change rate 10%
10.00
8.30
7.10
6.20
5.00
4.10
3.30
2.70
2.10
1.70
1.50
1.20
1.10
0.96
0.77
0.62
0.55
0.45
0.35
•
SSB64 Series (SSB 64-)
Model
Inductance
L(µH)
at 10 kHz, 1mA
R
dc
(m )
max.
Rated current
(A)
∆T=20˚C
∆T=40˚C
Current
(Ref.)
(A)
64-1R0
64-1R5
64-2R2
64-3R3
64-4R7
64-6R8
64-100
64-150
64-220
64-330
64-470
64-680
64-101
64-151
64-221
64-331
64-471
64-681
64-102
1.0±20%
1.5±20%
2.2±20%
3.3±20%
4.7±20%
6.8±20%
10±20%
15±20%
22±20%
33±20%
47±10%
68±10%
100±10%
150±10%
220±10%
330±10%
470±10%
680±10%
1000±10%
40
50
60
70
80
100
120
150
240
290
420
830
1000
1100
2400
3150
4000
6600
8400
1.70
1.50
1.50
1.50
1.40
1.30
1.20
1.00
0.80
0.70
0.55
0.40
0.35
0.30
0.30
0.20
0.19
0.15
0.14
2.30
2.10
2.10
2.10
1.90
1.80
1.60
1.40
1.10
0.98
0.77
0.56
0.49
0.42
0.42
0.28
0.26
0.21
0.19
L change rate 10%
11.60
10.00
7.70
6.30
5.30
4.30
3.60
2.90
2.40
2.00
1.60
1.40
1.00
0.86
0.71
0.59
0.49
0.41
0.34
•
SSB44 Series (SSB 44-)
Model
Inductance
L(µH)
at 10 kHz, 1mA
R
dc
(m )
max.
Rated current
(A)
∆T=20˚C
∆T=40˚C
Current
(Ref.)
(A)
44-1R0
44-1R5
44-2R2
44-3R3
44-4R7
44-6R8
44-100
44-150
44-220
44-330
44-470
44-680
44-101
44-151
44-221
44-331
44-471
44-681
1.0±20%
1.5±20%
2.2±20%
3.3±20%
4.7±20%
6.8±20%
10±20%
15±20%
22±20%
33±20%
47±10%
68±10%
100±10%
150±10%
220±10%
330±10%
470±10%
680±10%
70
70
100
100
100
130
170
270
370
550
820
920
1600
1900
3000
4900
7500
8300
1.90
1.90
1.60
1.50
1.30
1.20
0.85
0.75
0.65
0.45
0.40
0.35
0.25
0.22
0.20
0.15
0.12
0.10
2.60
2.60
2.20
2.10
1.80
1.60
1.10
1.00
0.91
0.63
0.56
0.49
0.35
0.30
0.28
0.21
0.16
0.14
L change rate 10%
6.70
5.80
4.70
3.90
3.10
2.60
2.10
1.70
1.30
1.10
0.97
0.83
0.71
0.57
0.46
0.38
0.31
0.29
• Operating temperature range: –20 to +105˚C (Includes self-temperature rise)
• Storage temperature range: –5 to +45˚C for 6 months (in taping state according to JIS C 0806)
Choke Coils VOL.02
29
SMD-Type
Shape and Dimensions
• SSB 15Series
7.0
max.
• SSB 14Series
6.0
max.
• SSB 84Series
• SSB 64Series
5.5
max.
4.8
max.
• SSB 44Series
8.5
max.
8.3
max.
11.6
max.
11.6
max.
6.3
max.
6.0
max.
10.0
max.
14.0
max.
14.0
max.
4.0
8.0
max.
6.5
max.
3.0
3.0
2.5
4.0
5.0
6.0
6.0
3.0
2.0
Electrode: PB material
Electrode: PB material
Electrode: brass
Electrode: brass
Electrode: PB material
[mm]
Recommended Land Pattern
bSSB14/15
Series
bSSB84
Series
12.7
3.65
5.4
3.1
9.6
3.4
4.6
bSSB64
Series
bSSB44
Series
3.6
7.6
2.6
2.4
2.35
6.1
1.4
3.6
3.1
[mm]
Choke Coils VOL.02
30
SMD-Type
Numbering System
SSB - 44 - 101
Series
Core size (indicated by the first numbers of the core’s diameter and height.)
Model and core size
The Models use 5-digit numbers that show the core size and inductance. The first two digits
show the core size, indicated by the first numbers of the core’s diameter and height.
Model
SSB 15-
SSB 14-
SSB 84-
SSB 64-
SSB 44-
Core size [
mm]
ø11.0 5.5
ø11.0 4.0
ø8.0 4.0
ø6.0 4.0
ø4.5 4.0
Inductance: 10 10
1
=100 (µH)
Choke Coils VOL.02
31
