FN685-10/03 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> filter> FN685-10/03

FN685-10/03: Description250V, 50/60 HZ, SINGLE PHASE EMI FILTER, ROHS COMPLIANT PACKAGE; CategoryAnalog mixed-signal IC filter; File Size201KB，4 Pages; ManufacturerSchaffner; Environmental Compliance

Download Datasheet Parametric Compare View All

FN685-10/03 Overview

250V, 50/60 HZ, SINGLE PHASE EMI FILTER, ROHS COMPLIANT PACKAGE

FN685-10/03 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Schaffner
package instruction	ROHS COMPLIANT PACKAGE
Reach Compliance Code	compliant
Other features	CLAMP TERMINAL WITH M4 SCREW CONNECTIONS
Certification	UL; CSA; ENEC-14
filter type	SINGLE PHASE EMI FILTER
high	50 mm
high potential	760 V
Maximum leakage current	0.41 mA
length	150 mm
Manufacturer's serial number	FN685
Installation type	PANEL MOUNT
working frequency	50/60 Hz
Maximum operating temperature	100 °C
Minimum operating temperature	-25 °C
physical size	L150.0XB75.0XH50.0 (mm)/L5.906XB2.953XH1.969 (inch)
Rated current	12 A
Rated voltage	250 V
Terminal surface	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

High-power Performance EMI Filter

Single-Phase Filters FN 685

Rated currents from 10 to 36 A

Excellent differential and common-mode

attenuation

Approvals

Features and benefits

FN 685 filters are designed for easy and fast chassis

mounting

FN 685 two-stage filters provide an excellent high

differential and common- mode attenuation

performance, based on chokes with high saturation

resistance and very good thermal behavior

FN 685 two-stage filters are designed for very high

noise suppression over a broad frequency range

Faston terminal connection with additional spade

solder possibility or screw mounting connection

Custom-specific versions on request

Technical specifications

Maximum continuous operating voltage

Operating frequency

Rated currents

High potential test voltage

250 VAC, 50/60 Hz

dc to 400 Hz

Typical applications

Electrical and electronic equipment

Consumer goods

Power supplies

10 to 36 A @ 40 °C max.

P –> PE 2000 VAC for 2 sec

Building automation

Elevators and cranes

Office automation equipment

Datacom equipment

Temperature range (operation and storage)

Flammability corresponding to

Design corresponding to

P –> N 760 VAC for 2 sec

-25 °C to +100 °C (25/100/21)

MTBF @ 40°C/230V (Mil-HB-217F)

UL 94 V-2 or better

UL 1283, CSA 22.2 No. 8 1986, IEC/EN 60939

400,000 hours

Typical electrical schematic
