3-1393136-0 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Mechanical and electronic products> relay> 3-1393136-0

3-1393136-0: DescriptionOFF-DELAY RELAY, DPDT, MOMENTARY, 10A (CONTACT), 30VDC (CONTACT), 0.1-10s, SOCKET MOUNT; CategoryMechanical and electronic products relay; File Size112KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

3-1393136-0 Overview

OFF-DELAY RELAY, DPDT, MOMENTARY, 10A (CONTACT), 30VDC (CONTACT), 0.1-10s, SOCKET MOUNT

3-1393136-0 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	TE Connectivity
Reach Compliance Code	unknown
ECCN code	EAR99
Maximum adjustable time delay	10 s
Minimum adjustable time delay	0.1 s
body width	45.2 mm
body height	74.6 mm
Body length or diameter	61.1 mm
Maximum coil voltage (AC)	24 V
Contact (AC) maximum rated R load	10A@277VAC
Maximum contact current (AC)	10 A
Maximum contact current (DC)	10 A
Contact (DC) maximum rated R load	10A@30VDC
Maximum contact voltage (AC)	277 V
Maximum contact voltage (DC)	30 V
Contact/Output Power Type	AC/DC
Manufacturer's serial number	1393136
Installation features	SOCKET MOUNT
Maximum operating temperature	55 °C
Minimum operating temperature	-10 °C
physical size	61.1mm X 45.2mm X 74.6mm
Guideline	CSA; UL
Relay action	MOMENTARY
Relay function	DPDT
Relay type	OFF-DELAY RELAY
surface mount	NO
Termination type	SNAP-ON
Base Number Matches	1

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Relays

Product Feature Selector

> Product Details

CB-1045B-38 Product Details

Time Delay Relays

Not EU R oHS or ELV C om plia nt

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

CB-1045B-38

(3-1393136-0)

T E I nternal N umber: 3 - 1 3 9 3 1 3 6 - 0

Product Highlights:

C B Series

Input Voltage = 24 VAC

C ontact Arrangement = 2 Form C , DPDT, 2 C /O

C ontact Rating = 10A @ 30 VDC or 277 VAC

Mounting Options = Socket

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

C B C MOS IC Time Delay Relay

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Termination Type = 11-Pin Octal Style Plug

Electrical Characteristics:

Input Voltage (VAC ) = 24

C ontact Rating = 10A @ 30 VDC or 277 VAC

Body Related Features:

Series

= C B

Contact Related Features:

Mounting Options = Socket

Mode of Operation = Delay on Release

Delay Time = 0.1 seconds to 10 seconds

Type of C ontrol = Knob

Repeatability, Max. = ± 2%

Approved Standards = C SA C ertified, UL Recognized

C ontact Base Material = Silver C admium Oxide

Approx. Dimensions (L x W x H) (mm [in]) = 61.10 x 45.20 x 74.60

[2.407 x 1.780 x 2.939]

Enclosure = White Plastic C ase

Configuration Related Features:

C ontact Arrangement

= 2 Form C , DPDT, 2 C /O

Multiple Timing Ranges = Without

Industry Standards:

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Not relevant for lead free process

Conditions for Usage:

Temperature Range (?C ) = -10 – +55

Other:

Brand = Potter & Brumfield

Additional Information:

Product Line Information

Additional Product Images:

Schematic

Wiring Diagram

3-1393136-0 Related Products

	3-1393136-0	CB-1045B-38
Description	OFF-DELAY RELAY, DPDT, MOMENTARY, 10A (CONTACT), 30VDC (CONTACT), 0.1-10s, SOCKET MOUNT	OFF-DELAY RELAY, DPDT, MOMENTARY, 3000mW (COIL), 10A (CONTACT), 30VDC (CONTACT), 0.1-10s, SOCKET MOUNT
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
Maximum adjustable time delay	10 s	10 s
Minimum adjustable time delay	0.1 s	0.1 s
body width	45.2 mm	45.2 mm
body height	74.6 mm	74.6 mm
Body length or diameter	61.1 mm	61.1 mm
Maximum coil voltage (AC)	24 V	24 V
Contact (AC) maximum rated R load	10A@277VAC	10A@277VAC
Maximum contact current (AC)	10 A	10 A
Maximum contact current (DC)	10 A	10 A
Contact (DC) maximum rated R load	10A@30VDC	10A@30VDC
Maximum contact voltage (AC)	277 V	277 V
Maximum contact voltage (DC)	30 V	30 V
Contact/Output Power Type	AC/DC	AC/DC
Manufacturer's serial number	1393136	CB
Installation features	SOCKET MOUNT	SOCKET MOUNT
Maximum operating temperature	55 °C	55 °C
Minimum operating temperature	-10 °C	-10 °C
physical size	61.1mm X 45.2mm X 74.6mm	61.1mm X 45.2mm X 74.6mm
Guideline	CSA; UL	CSA; UL
Relay action	MOMENTARY	MOMENTARY
Relay function	DPDT	DPDT
Relay type	OFF-DELAY RELAY	OFF-DELAY RELAY
surface mount	NO	NO
Termination type	SNAP-ON	SNAP-ON
Base Number Matches	1	1
