Part Number

Search

3-1618241-3

Description
POWER/SIGNAL RELAY, SPST, MOMENTARY, 26.5VDC (COIL), 10A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT
CategoryMechanical and electronic products    relay
File Size115KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

3-1618241-3 Online Shopping

Suppliers Part Number Price MOQ In stock
3-1618241-3 - - View Buy Now

3-1618241-3 Overview

POWER/SIGNAL RELAY, SPST, MOMENTARY, 26.5VDC (COIL), 10A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT

3-1618241-3 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
Objectid1668065829
Reach Compliance Codecompliant
ECCN codeEAR99
Samacsys DescriptionK81B345=RELAY, VACUUM, SPST-NC
Samacsys ManufacturerTE Connectivity
Samacsys Modified On2020-10-04 19:49:56
Coil resistance290 Ω
Maximum coil voltage (DC)26.5 V
Maximum contact current (AC)30 A
Maximum contact current (DC)30 A
Maximum contact voltage (DC)10 V
Contact/Output Power TypeAC/DC
Installation featuresPANEL MOUNT
Relay actionMOMENTARY
Relay style1 FORM B
Relay functionSPST-NC
Relay typePOWER/SIGNAL RELAY
surface mountNO
Termination typeSNAP-ON
My Account
Tyco Electronics
(C hange)
Se a rch by Ke yword or Pa rt #
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Relays
>
Product Feature Selector
> Product Details
K81B345 Product Details
High Voltage Relays
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
K81B345
(3-1618241-3)
T E I nternal N umber: 3 - 1 6 1 8 2 4 1 - 3
Product Highlights:
l
C ontact Arrangement = 1 Form B, SPST-NC , 1 N/C
l
Power Switching = Make Only, Yes, No
l
C ontact C urrent Rating = 0 - 10 Amps.
l
Not RF Rated
l
C oil Voltage = 26.5 VDC
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Termination Style
= PC B Tail
Electrical Characteristics:
l
C ontact C urrent Rating (Amps.)
= 0 – 10
l
RF Rated
= No
l
C oil Voltage (VDC )
= 26.5
l
Voltage, Max. (VDC )
= 0 – 10000
l
C urrent, C arry Only = Yes
Termination Related Features:
l
High Voltage C onnection (Power)
= Flying Leads
l
High Voltage C onnection (C oil)
= PC B Tail
l
Auxiliary C ontacts
= Without
Body Related Features:
l
Mount Style
= Printed C ircuit Board
Configuration Related Features:
l
C ontact Arrangement
= 1 Form B, SPST-NC , 1 N/C
l
Power Switching
= Make Only, Yes, No
l
High Voltage C onnection Length (mm [in])
= 304.8 [12]
l
Economizer
= Without
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not suitable for lead free processing
Other:
l
Brand = Kilovac
