3KDAT-15R5-SNT datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Radio frequency and microwave> 3KDAT-15R5-SNT

3KDAT-15R5-SNT: DescriptionVariable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, 4 X 4 MM, DG983-1, 20 PIN; CategoryWireless rf/communication Radio frequency and microwave; File Size815KB，12 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com

Download Datasheet Parametric Compare View All

3KDAT-15R5-SNT Overview

Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, 4 X 4 MM, DG983-1, 20 PIN

3KDAT-15R5-SNT Parametric

Parameter Name	Attribute value
Maker	Mini-Circuits
Reach Compliance Code	unknown
Other features	CMOS COMPATIBLE
Nominal attenuation	15.5 dB
Characteristic impedance	50 Ω
structure	COMPONENT
Maximum input power (CW)	23.98 dBm
Maximum insertion loss	4.7 dB
JESD-609 code	e0
Maximum operating frequency	4000 MHz
Minimum operating frequency
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
RF/Microwave Device Types	VARIABLE ATTENUATOR
Terminal surface	TIN LEAD
Maximum voltage standing wave ratio	2.1
Base Number Matches	1
