5962-8956201XX: DescriptionIC SWITCHED CAPACITOR REGULATOR, 40 kHz SWITCHING FREQ-MAX, MBCY8, METAL CAN, 8 PIN, Switching Regulator or Controller; CategoryPower/power management The power supply circuit; File Size482KB，12 Pages; ManufacturerLinear ( ADI ); Websitehttp://www.analog.com/cn/index.html

Download Datasheet Parametric Compare View All

5962-8956201XX Overview

IC SWITCHED CAPACITOR REGULATOR, 40 kHz SWITCHING FREQ-MAX, MBCY8, METAL CAN, 8 PIN, Switching Regulator or Controller

5962-8956201XX Parametric

Parameter Name	Attribute value
Maker	Linear ( ADI )
Parts packaging code	BCY
package instruction	,
Contacts	8
Reach Compliance Code	unknown
ECCN code	EAR99
Analog Integrated Circuits - Other Types	SWITCHED CAPACITOR REGULATOR
Maximum input voltage	15 V
Minimum input voltage	3.5 V
Nominal input voltage	7 V
JESD-30 code	O-MBCY-W8
JESD-609 code	e0
Number of functions	1
Number of terminals	8
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	METAL
Package shape	ROUND
Package form	CYLINDRICAL
Certification status	Not Qualified
surface mount	NO
Maximum switching frequency	40 kHz
Temperature level	MILITARY
Terminal surface	TIN LEAD
Terminal form	WIRE
Terminal location	BOTTOM
Base Number Matches	1

Preview

Download Datasheet

View All

5962-8956201XX Related Products

	5962-8956201XX	5962-8956201PX	5962-8956201XA	5962-8956201GA	LT1054MH/883	LT1054MJ8/883	5962-8956201PA
Description	IC SWITCHED CAPACITOR REGULATOR, 40 kHz SWITCHING FREQ-MAX, MBCY8, METAL CAN, 8 PIN, Switching Regulator or Controller	IC SWITCHED CAPACITOR REGULATOR, 25 kHz SWITCHING FREQ-MAX, CDIP8, CERDIP-8, Switching Regulator or Controller	IC SWITCHED CAPACITOR REGULATOR, 40 kHz SWITCHING FREQ-MAX, MBCY8, METAL CAN, 8 PIN, Switching Regulator or Controller	IC SWITCHED CAPACITOR REGULATOR, 25 kHz SWITCHING FREQ-MAX, MBCY8, METAL CAN, TO-5, 8 PIN, Switching Regulator or Controller	IC SWITCHED CAPACITOR REGULATOR, 25 kHz SWITCHING FREQ-MAX, MBCY8, METAL CAN, TO-5, 8 PIN, Switching Regulator or Controller	IC SWITCHED CAPACITOR REGULATOR, 25 kHz SWITCHING FREQ-MAX, CDIP8, CERDIP-8, Switching Regulator or Controller	IC SWITCHED CAPACITOR REGULATOR, 25 kHz SWITCHING FREQ-MAX, CDIP8, CERDIP-8, Switching Regulator or Controller
Maker	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )	Linear ( ADI )
Parts packaging code	BCY	DIP	BCY	TO-5	TO-5	DIP	DIP
package instruction	,	DIP,	METAL CAN, 8 PIN	TO-5,	TO-5, CAN8,.2	DIP, DIP8,.3	DIP, DIP8,.3
Contacts	8	8	8	8	8	8	8
Reach Compliance Code	unknown	compliant	unknown	unknown	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Analog Integrated Circuits - Other Types	SWITCHED CAPACITOR REGULATOR	SWITCHED CAPACITOR REGULATOR	SWITCHED CAPACITOR REGULATOR	SWITCHED CAPACITOR REGULATOR	SWITCHED CAPACITOR REGULATOR	SWITCHED CAPACITOR REGULATOR	SWITCHED CAPACITOR REGULATOR
Maximum input voltage	15 V	15 V	15 V	15 V	15 V	15 V	15 V
Minimum input voltage	3.5 V	3.5 V	3.5 V	3.5 V	3.5 V	3.5 V	3.5 V
JESD-30 code	O-MBCY-W8	R-GDIP-T8	O-MBCY-W8	O-MBCY-W8	O-MBCY-W8	R-GDIP-T8	R-GDIP-T8
JESD-609 code	e0	e0	e0	e0	e0	e0	e0
Number of functions	1	1	1	1	1	1	1
Number of terminals	8	8	8	8	8	8	8
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Package body material	METAL	CERAMIC, GLASS-SEALED	METAL	METAL	METAL	CERAMIC, GLASS-SEALED	CERAMIC, GLASS-SEALED
Package shape	ROUND	RECTANGULAR	ROUND	ROUND	ROUND	RECTANGULAR	RECTANGULAR
Package form	CYLINDRICAL	IN-LINE	CYLINDRICAL	CYLINDRICAL	CYLINDRICAL	IN-LINE	IN-LINE
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	NO	NO	NO	NO	NO	NO	NO
Maximum switching frequency	40 kHz	25 kHz	40 kHz	25 kHz	25 kHz	25 kHz	25 kHz
Temperature level	MILITARY	MILITARY	MILITARY	MILITARY	MILITARY	MILITARY	MILITARY
Terminal surface	TIN LEAD	TIN LEAD	Tin/Lead (Sn/Pb) - hot dipped	TIN LEAD	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb) - hot dipped
Terminal form	WIRE	THROUGH-HOLE	WIRE	WIRE	WIRE	THROUGH-HOLE	THROUGH-HOLE
Terminal location	BOTTOM	DUAL	BOTTOM	BOTTOM	BOTTOM	DUAL	DUAL
Base Number Matches	1	1	1	1	-	-	-
Is it lead-free?	-	Contains lead	-	-	Contains lead	Contains lead	Contains lead
Is it Rohs certified?	-	incompatible	incompatible	-	incompatible	incompatible	incompatible
encapsulated code	-	DIP	-	TO-5	TO-5	DIP	DIP
Peak Reflow Temperature (Celsius)	-	NOT SPECIFIED	-	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Switch configuration	-	DOUBLER INVERTER	-	DOUBLER INVERTER	DOUBLER INVERTER	DOUBLER INVERTER	DOUBLER INVERTER
technology	-	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR
Maximum time at peak reflow temperature	-	NOT SPECIFIED	-	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
control mode	-	-	VOLTAGE-MODE	-	VOLTAGE-MODE	VOLTAGE-MODE	VOLTAGE-MODE
Maximum output current	-	-	0.1 A	-	0.1 A	0.1 A	0.1 A
Encapsulate equivalent code	-	-	CAN8,.23	-	CAN8,.2	DIP8,.3	DIP8,.3
Nominal output voltage	-	-	-	-5 V	-5 V	-5 V	-5 V
Maximum supply current (Isup)	-	-	-	5 mA	5 mA	5 mA	5 mA
