LOS4601-2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> LOS4601-2

LOS4601-2: DescriptionAC-DC Regulated Power Supply Module, 1 Output, 15W, Hybrid,; CategoryPower/power management The power supply circuit; File Size330KB，12 Pages; ManufacturerBel Fuse

Download Datasheet Parametric Compare View All

LOS4601-2 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	LOS4601-2	-	-	View	Buy Now

LOS4601-2 Overview

AC-DC Regulated Power Supply Module, 1 Output, 15W, Hybrid,

LOS4601-2 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
package instruction	,
Reach Compliance Code	compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	AC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	264 V
Minimum input voltage	85 V
Nominal input voltage	110 V
JESD-30 code	R-XXMA-X
JESD-609 code	e0
Number of functions	1
Output times	1
Maximum operating temperature	50 °C
Minimum operating temperature	-10 °C
Maximum output voltage	26.4 V
Minimum output voltage	21.6 V
Nominal output voltage	24 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	COMMERCIAL
Terminal surface	TIN LEAD
Terminal form	UNSPECIFIED
Terminal location	UNSPECIFIED
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	15 W
Fine-tuning/adjustable output	YES
Base Number Matches	1

Preview

Download Datasheet

View All

LOS, LOR, LOK4000 Series Data Sheet

DIN-Rail Mountable AC-DC (DC-DC) Converters

15, 30, 50 Watt AC-DC (DC-DC) Converters Convert Simply

Features

• RoHS lead-free-solder

products available

and

lead-solder-exempted

• Universal input range 100 – 240 VAC nominal

• Additional DC input 90 – 250 VDC

• Class I equipment

• Single output 5.1, 12, 24, or 48 VDC

• Extremely compact design

• Battery charger versions

• Operating ambient temperature range –10 to 50 °C

with convection cooling

• Short-circuit and no-load proof

Safety according to IEC/EN 60950-1

, UL/CSA 60950-1,

and UL 508

PRODUCT SERVICE

roduction monitored

ype tested

LOK

LOS/LOR

Description

The Convert Simply front-end converters represent a family of

15, 30, and 50 watt DIN-rail mountable AC-DC converters for

use as rectifiers or battery chargers. Plastic casing, compact

size, and high reliability make the LOS, LOR, LOK4000 Series

an excellent choice for space-critical applications, where a

DIN-Rail mountable AC-DC converter is required. The

universal input range and a built-in input filter allow flexible

operation in a wide variety of electronic equipment and

enables worldwide connection to the mains.

The converters are available as rectifiers with 12 V, 24 V, or 48

V single output and as battery chargers for 12 V, 24 V, or 48 V

batteries. The output voltage of LOK converters can be

adjusted via the R input.

Safety approvals fully comply with worldwide requirements.

Applications

Typical applications are: powering building controls, factory

automation, industrial controls, instrumentation, electromag-

netic drives, fans, and other DC loads.

Table of Contents

Page

Electromagnetic Compatibility (EMC) .............................. 7

Mechanical Data .............................................................. 8

Immunity to Environmental Conditions ............................. 8

Safety and Installation Instructions .................................. 9

Description of Options .................................................... 11

EC Declaration of Conformity LOS/LOR ........................ 12

Description ....................................................................... 1

Model Selection ............................................................... 2

Functional Description ..................................................... 3

Electrical Input Data ......................................................... 3

Electrical Output Data ...................................................... 4

Auxiliary Functions ........................................................... 6

BCD20035-G Rev AA, 25-Feb-09

Page 1 of 12

www.power-one.com

LOS4601-2 Related Products

	LOS4601-2	LOK4801-2R
Description	AC-DC Regulated Power Supply Module, 1 Output, 15W, Hybrid,	AC-DC Regulated Power Supply Module, 1 Output, 50W, Hybrid,
Is it Rohs certified?	incompatible	incompatible
Reach Compliance Code	compliant	compliant
ECCN code	EAR99	EAR99
Analog Integrated Circuits - Other Types	AC-DC REGULATED POWER SUPPLY MODULE	AC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	264 V	264 V
Minimum input voltage	85 V	85 V
Nominal input voltage	110 V	110 V
JESD-30 code	R-XXMA-X	R-XXMA-X
JESD-609 code	e0	e0
Number of functions	1	1
Output times	1	1
Maximum operating temperature	50 °C	50 °C
Minimum operating temperature	-10 °C	-10 °C
Maximum output voltage	26.4 V	52.8 V
Minimum output voltage	21.6 V	43.2 V
Nominal output voltage	24 V	48 V
Package body material	UNSPECIFIED	UNSPECIFIED
Package shape	RECTANGULAR	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED
Certification status	Not Qualified	Not Qualified
surface mount	NO	NO
technology	HYBRID	HYBRID
Temperature level	COMMERCIAL	COMMERCIAL
Terminal surface	TIN LEAD	TIN LEAD
Terminal form	UNSPECIFIED	UNSPECIFIED
Terminal location	UNSPECIFIED	UNSPECIFIED
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED
Maximum total power output	15 W	50 W
Fine-tuning/adjustable output	YES	YES
