Flexible Interconnections
Flexstrip
®
.100" PITCH FLEXSTRIP
®
INSERT MOLDED HEADER
LR49571
E60980
P
HYSICAL
P
ROPERTIES
I
NSULATION
M
ATERIAL
:
Socket – Glass reinforced thermoplastic, rated
UL 94V-0
Jumper – Nomex, Polyester, Teflon, Kapton
Locking – Nylon
H
OUSING
(L
OCKING
) C
OLOR
:
Socket – blue, Jumper – black
E
LECTRICAL
P
ROPERTIES
C
ONTACT
P
LATING
:
Tin plating
C
URRENT
R
ATING
:
2 amps per conductor
E
NVIRONMENTAL
P
ROPERTIES
T
EMPERATURE
R
ATING
:
Nomex* 105˚C
Polyester 105˚C
Teflon* 125˚C
Kapton* 150˚C
M
ATING
C
ONNECTOR
See page 166
NO. OF
POSITIONS
8
9
10
14
16
18
20
22
24
DIMENSIONS
A
21.8
24.4
26.9
37.1
42.2
45.7
52.3
57.4
62.5
B
17.78
20.32
22.86
33.02
38.1
43.18
48.26
53.34
58.42
Insert–Molded Jumper
FH N 1.85 A 16
Product Code
Number of
Conductors
Pin Configuration
Length
Insulation Material
N – Nomex
T – Teflon
K – Kapton
P – Polyester
Length of Jumper
.75" to 34"
Length
Thomas & Betts Electronics/OEM Division Tel: 901-252-5000 Fax: 901-252-1312
Dimensions shown are for reference only. Dimensions are in millimeters (inches).
