VCD30-D24-S5

Description
DC/DC converter
File Size408KB,3 Pages
ManufacturerCUI
Websitehttp://www.cui.com
Download Datasheet View All

VCD30-D24-S5 Overview

DC/DC converter

For more information, please visit the
product page.
rev.
page
date
1 of 3
08/2007
PART NUMBER:
VCD30 series
DESCRIPTION:
DC/DC converter
features
·25-30W isolated output
·efficiency to 85%
·2:1 input range
·six sided shield
·remote on/off control
·output trimming
model
number
VCD30-D12-S3R3
VCD30-D12-S5
VCD30-D12-S12
VCD30-D12-S15
VCD30-D12-D5
VCD30-D12-D12
VCD30-D12-D15
VCD30-D12-T512
VCD30-D15-T515
VCD30-D24-S3R3
VCD30-D24-S5
VCD30-D24-S12
VCD30-D24-S15
VCD30-D24-D5
VCD30-D24-D12
VCD30-D24-D15
VCD30-D24-T512
VCD30-D24-T515
VCD30-D48-S3R3
VCD30-D48-S5
VCD30-D24-S12
VCD30-D48-S15
VCD30-D48-D5
VCD30-D48-D12
VCD30-D48-D15
VCD30-D48-T512
VCD30-D48-T515
input
voltage
9-18VDC
9-18VDC
9-18VDC
9-18VDC
9-18VDC
9-18VDC
9-18VDC
9-18VDC
9-18VDC
18-36VDC
18-36VDC
18-36VDC
18-36VDC
18-36VDC
18-36VDC
18-36VDC
18-36VDC
18-36VDC
36-72VDC
36-72VDC
36-72VDC
36-72VDC
36-72VDC
36-72VDC
36-72VDC
36-72VDC
36-72VDC
output
voltage
3.3VDC
5VDC
12VDC
15VDC
±5VDC
±12VDC
±15VDC
5/±12VDC
5/±15VDC
3.3VDC
5VDC
12VDC
15VDC
±5VDC
±12VDC
±15VDC
5/±12VDC
5/±15VDC
3.3VDC
5VDC
12VDC
15VDC
±5VDC
±12VDC
±15VDC
5/±12VDC
5/±15VDC
output
current
5000mA
5000mA
2500mA
2000mA
±2500mA
±1250mA
±1000mA
3500/±310mA
3500/±250mA
5000mA
5000mA
2500mA
2000mA
±2500mA
±1250mA
±1000mA
3500/±310mA
3500/±250mA
5000mA
5000mA
2500mA
2000mA
±2500mA
±1250mA
±1000mA
3500/±310mA
3500/±250mA
input current
no load
full load
30mA
30mA
30mA
30mA
35mA
35mA
35mA
35mA
35mA
30mA
30mA
30mA
30mA
30mA
30mA
30mA
30mA
30mA
20mA
20mA
20mA
20mA
25mA
25mA
25mA
25mA
25mA
1860mA
2675mA
3050mA
3050mA
2675mA
3050mA
3050mA
2640mA
2640mA
920mA
1336mA
1525mA
1525mA
1336mA
1470mA
1470mA
1320mA
1320mA
460mA
660mA
765mA
765mA
660mA
735mA
735mA
655mA
655mA
efficiency
74%
78%
82%
82%
78%
82%
82%
79%
79%
75%
79%
82%
82%
79%
85%
85%
80%
80%
75%
79%
82%
82%
79%
85%
85%
80%
80%
20050
SW
112
th
Ave. Tualatin, Oregon
97062
phone
503.612.2300
fax
503.612.2382
