Part Number

Search

F535LR-133MHZ-BM0Z

Description
HCMOS Output Clock Oscillator, 133MHz Nom, ROHS COMPLIANT, SMD, 4 PIN
CategoryPassive components    oscillator
File Size192KB,2 Pages
ManufacturerFOX [Fox Electronics]
Environmental Compliance
Download Datasheet Parametric View All

F535LR-133MHZ-BM0Z Overview

HCMOS Output Clock Oscillator, 133MHz Nom, ROHS COMPLIANT, SMD, 4 PIN

F535LR-133MHZ-BM0Z Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
package instructionROHS COMPLIANT, SMD, 4 PIN
Reach Compliance Codecompliant
ECCN codeEAR99
Other featuresENABLE/DISABLE FUNCTION; TAPE AND REEL
maximum descent time7 ns
Frequency Adjustment - MechanicalNO
frequency stability50%
JESD-609 codee4
Installation featuresSURFACE MOUNT
Nominal operating frequency133 MHz
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Oscillator typeHCMOS
Output load15 pF
physical size5.0mm x 3.2mm x 1.3mm
longest rise time7 ns
Maximum supply voltage3.63 V
Minimum supply voltage2.97 V
Nominal supply voltage3.3 V
surface mountYES
maximum symmetry60/40 %
Terminal surfaceGold (Au)
Base Number Matches1
HcMOS 5x3.2mm 3.3V SMD Oscillator
Model: F530l SERIES
Page 1 of 2
RoHS compliant / Pb Free
Rev. 10/23/2008
http://www.foxonline.com/need_a_sample.htm
FEATuRES
• 3.3V Operation
• Standby Function
• Tape and Reel
(2,000 pcs. STD)
OPTIONS
• 5.0V (F550L) Version Available
XpressO
®
Equivalent
FXO-HC53
Why XpressO?
Lower Cost, Faster Delivery, Low Jitter!
• PART NuMbER SElEcTION
Learn More - Internet Required
Part Number
474-Frequency-xxxxx
475-Frequency-xxxxx
476-Frequency-xxxxx
550-Frequency-xxxxx
492-Frequency-xxxxx
636-Frequency-xxxxx
546-Frequency-xxxxx
Model
Number
F530L
F530LR
F535L
F535LR
F536L
F536LR
F538L
Frequency
Operating
Stability
1
Temperature (ºC)
±100PPM
-10 ~ +70
±100PPM
-40 ~ +85
±50PPM
-10 ~ +70
±50PPM
-40 ~ +85
±25PPM
-10 ~ +70
±25PPM*
-40 ~ +85
±20PPM*
-10 ~ +70
Frequency
Range (MHz)
1.544 ~ 155.520
1.544 ~ 155.520
1.544 ~ 155.520
1.544 ~ 155.520
1.544 ~ 155.520
1.544 ~ 155.520
1.544 ~ 77.760
#4
5.0 ± 0.2
#3
Top
View
Dot denotes
pin 1
3.2 ± 0.2
#1
#2
• ElEcTRIcAl cHARAcTERISTIcS
PARAMETERS
Frequency Range (F
o
)
Storage Temperature Range (T
stg
)
Supply Voltage
(V
dd
)
Input Current
(I
dd
)
1.544 ~ 32.000 MHz
32.000+ ~ 50.000 MHz
50.000+ ~ 67.000 MHz
67.000+ ~ 155.520 MHz
Output Symmetry (50% V
dd
)
Rise Time (10% ~ 90% V
dd
) (T
r
)
Fall Time (90% ~ 10% V
dd
) (T
f
)
Output Voltage
(V
ol
)
(V
oh
)
Output Current
(I
ol
)
(I
oh
)
Output Load
(HCMOS)
Standby Current
Start-up Time
(T
s
)
Output Disable Time
2
Output Enable Time
2
Reflow Soldering Temp
Moisture Sensitivity Level (MSL)
Termination Finish
1
1 .3 M ax
MAX
(unless otherwise noted)
1.544 ~ 155.520 MHz
-55ºC ~ +125ºC
3.3V ± 10%
15mA
20mA
25mA
40mA
40% ~ 60%
7nS
7nS
10% V
dd
90% V
dd
Min
2mA Min
-2mA Min
15pF
10µA
10mS
150nS
10mS
260ºC / 10 Seconds
1
Au
Bottom
View
2.54±0.1
#1
#2
#4
#3
1 .0
1.2
Recommended
Solder Pad Layout
2.54
1.2 9
2 .25
1.24
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration. *Excludes Shock/Vibration
2
An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.
Note: A 0.01µF bypass capacitor should be placed between V
dd
(Pin 4) and GND (Pin 2) to
minimize power supply line noise.
Drawing is for reference to critical specifications defined by size measurements.
Certain non-critical visual attributes, such as side castellations, reference pin shape, etc. may
vary. All specifications subject to change without notice.
Pin Connections
# 1 E /D
#2 G ND
# 3 O u tp u t
#4 V
D D
• ENAblE / DISAblE FuNcTION
INH (Pin 1)
OUTPUT (Pin 3)
2
OPEN
ACTIVE
'1' Level V
ih
70% V
dd
ACTIVE
'0' Level V
il
30% V
dd
High Z
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
© 2008 FOX ELECTRONICS | ISO9001:2000 Certified
EMEA
Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282
|
Japan
Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
