DUAL-IN-LINE SOCKETS
Disposable Metal Carrier
SOLDER TAIL
•
Allows for maximum air circulation
under the ICs.
•
Sockets are XY stackable.
•
Socket pins feature closed-end
construction eliminating any solder
wicking problems.
•
Series 694 use MM #0132, #0135,
#0255, #0442, #0548, #0552-1,
#0552-2, #1401 or #8855 pins.
See pages 126, 127, 134, 139
and 140 for details.
•
Direct visibilty for soldering,
inspection and repair.
Series 694
Fig. 1
For RoHS compliance
select plating code.
Total number
of pins
LOW PROFILE
Quantity
per tube
Ordering Information
XX= Plating Code
See Below
694-XX-306-00-67Y000
694-XX-308-00-67Y000
694-XX-314-00-67Y000
694-XX-316-00-67Y000
694-XX-318-00-67Y000
694-XX-320-00-67Y000
694-XX-322-00-67Y000
694-XX-324-00-67Y000
694-XX-424-00-67Y000
694-XX-624-00-67Y000
694-XX-628-00-67Y000
694-XX-632-00-67Y000
694-XX-640-00-67Y000
A
0.3
0.4
0.7
0.8
0.9
1.0
1.1
1.2
1.2
1.2
1.4
1.6
2.0
B
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.4
0.6
0.6
0.6
0.6
C
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.5
0.7
0.7
0.7
0.7
67
50
28
25
22
20
18
16
16
16
14
12
10
Fig. 2
ULTRA LOW PROFILE
6
8
14
16
18
20
22
24
24
24
28
32
40
Fig. 3
Socket Pin Information
Terminal Length
.136
.136
.125
.170
.165
.143
.180
.275
.155
Body Diameter
.038
.038
.020
.038
.053
.020
.020
.020
.034
93
30μ” Au
99
200μ”Sn/Pb
43
200μ”Sn
30μ” Au
200μ” Sn/Pb 200μ”Sn/Pb
REDUCED BARRELL
Fig. 4
Y
Y
Y
Y
Y
Y
Y
Y
Y
=
=
=
=
=
=
=
=
=
0
1
2
3
4
5
6
7
8
Fig. #
3
3
1
3
2
1
1
1
4
44
200μ”Sn
200μ”Sn
SPECIFY PLATING CODE XX=
Sleeve (Pin)
Contact (Clip)
