P/N: B-1x/1x-1250C-F(DFB)-SSCx-G5
1.25 Gbps bi-directional SC Receptacle
Single Fiber Transceiver
Features
Single Mode Single Fiber 2x5 SFF SC Receptacle
connector
Gigabit Ethernet Compliant
Single +3.3V Power Supply
Tx 1310nm/Rx 1550 nm
[B-13/15-1250C-F(DFB)-SSCx]
Tx 1550nm/Rx 1310 nm
[B-15/13-1250C-F(DFB)-SSCx]
LVPECL Differential Inputs and Outputs
LVTTL Signal Detection Output
Class 1 Laser Int. Safety Standard IEC-825 Compliant
EMI Shielding Finger Optional
RoHS compliance available
Table 1 – Absolute Maximum Rating
Parameter
Power Supply Voltage
Input Voltage
Output Current
Soldering Temperature
Storage Temperature
Symbol
Vcc
-
I
out
-
Tstg
Min.
0
0
-
-
-40
Typical
-
-
-
-
-
Max.
3.6
Vcc
30
260
85
Unit
V
V
mA
o
o
Notes
C
C
1
Note 1: 10 senconds on leads only
Table 2 – Recommended Operating Condition
Parameter
Power Supply Voltage
Operating Temperature (-SSCx)
Operating Temperature (-SSCxA)
Data Rate
Symbol
Vcc
Topr
Topr
-
Min.
3.1
-5
-40
-
-
1250
Typical
3.3
Max.
3.5
70
85
-
Unit
V
o
o
Notes
C
C
Mbps
-1-
DS-6363
Rev 0.1 2010-12-13
P/N: B-1x/1x-1250C-F(DFB)-SSCx-G5
1.25 Gbps bi-directional SC Receptacle
Single Fiber Transceiver
Table 3 – Transmitter Specifications (Optical)
Parameter
Optical Transmit Power
Optical Transmit Power
Optical Transmit Power
Optical Transmit Power
Output Center Wavelength
Output Center Wavelength
Output Spectrum Width
Output Spectrum Width
Side Mode Suppression Ratio
Optical Rise/Fall Time
Extinction Ratio
Output Eye
Optical Isolation
Relative Intensity Noise
Symbol
P
o
P
o
P
o
P
o
λ
c
λ
c
Δλ
rms
Δλ
Sr
t
r
/t
f
ER
-
RIN
Min.
-9
-5
-3
0
1260
1480
-
-
30
-
9
30
-
-
Typical
-
-
-
-
1310
1550
-
-
-
-
-
-
-
-
Max.
-3
0
+2
+5
1360
1580
4
1
-
260
-
-
-116
270
Unit
dBm
dBm
dBm
dBm
nm
nm
nm
nm
dB
ps
dB
dB
dB/Hz
ps
12
Notes
2
3
4
5
6
7
8
9
10
11
Compliant with ITU-T recommendation G.957/STM-1
Total Jitter
T
J
Note 2: B-1x/1x-1250C-F(DFB)-SSC
Note 3: B-1x/1x-1250C-F(DFB)-SSC2
Note 4: B-1x/1x-1250C-F(DFB)-SSC3
Note 5: B-1x/1x-1250C-F(DFB)-SSC4
Note 6: B-13/15-1250C-F(DFB)-SSCx
Note 7: B-15/13-1250C-F(DFB)-SSCx
Note 8: RMS(σ), B-1x/1x-1250C-F-SSC
Note 9: -20dB width, B-1X/1X-1250C-FDFB-SSCx
Note 10: B-1x/1x-1250C-FDFB-SSCx
Note 11: 20% to 80% Values
Note 12: Measured with 2
7
-1 PRBS
Table 4 – Transmitter Specifications (Electrical)
Parameter
Power Supply Current
Transmit Enable Voltagea
Transmit Disable Voltage
Data Input Current-Low
Data Input Current-High
Differential Input Voltage
Data Input Voltage-Low
Data Input Voltage-High
Symbol
I
CC
V
EN
V
DIS
I
IL
I
IH
V
IH
-V
IL
V
IL
-V
CC
V
IH
-V
CC
Min.
-
0
2
-350
-
300
-2.0
-1.1
Typical
-
-
-
-
-
-
-
-
Max.
150
0.8
V
CC
-
350
-
-1.58
-0.74
Unit
mA
V
V
μA
μA
mV
mV
mV
Notes
13
14
Note 13: Maximum current is specified at Vcc=Maximum @ maximum temperature
Note 14: These inputs are compatible with 10K, 10KH and 100K ECL and PECL inputs
-2-
DS-6363
Rev 0.1 2010-12-13
P/N: B-1x/1x-1250C-F(DFB)-SSCx-G5
1.25 Gbps bi-directional SC Receptacle
Single Fiber Transceiver
Table 5 – Receiver Specifications (Optical)
Parameter
Sensitivity
Maximum Input Power
Signal Detect-Asserted
Signal Detect-Deasserted
Signal Detect-Hysteresis
Cross Talk
Wavelength of Operation
Wavelength of Operation
Symbol
-
P
in
Pa
Pd
-
-
Min.
-
-3
-
-38
1.0
-
1480
1260
Typical
-
-
-
-
-
-
-
-
Max.
-22
-
-22
-
4.0
-33
1600
1360
Unit
dBm
dBm
dBm
dBm
dB
dB
nm
nm
18
19
16
17
Notes
15
Note 15: Measured with 2
7
-1 PRBS,BER= 10
-12
Note 16: Measured on transition: low to high, The SD level should be deasserted when fiber disconnected
Note 17: Measured on transition: high to low, The SD level should be deasserted when fiber disconnected
Note 18: B-13/15-1250C-F(DFB)-SSCx
Note 19: B-15/13-1250C-F(DFB)-SSCx
Table 6 – Receiver Specifications (Electrical)
Parameter
Power Supply Current
Data Output Voltage-Low
Data Output Voltage-High
Signal Detect Output Voltage-Low
Signal Detect Output Voltage-High
Symbol
I
CC
V
OL
-V
CC
V
OH
-V
CC
V
SDL
V
SDH
Min.
-
-2.0
-1.1
0
2.0
Typical
-
-
-
-
-
Max.
100
-1.58
-0.74
0.5
V
CC
Unit
mA
V
V
V
V
Notes
20
21
22
Note 20: The current excludes the output load current
Note 21: These outputs are compatible with 10K, 10KH and 100KECL and PECL outputs
Note 22: LVTTL SD Output
-3-
DS-6363
Rev 0.1 2010-12-13
P/N: B-1x/1x-1250C-F(DFB)-SSCx-G5
1.25 Gbps bi-directional SC Receptacle
Single Fiber Transceiver
Connection Diagram
Mounting Studs Solder Posts
10 9
8
7
6
10-PIN MODULE - Bottom VIEW
1
2
3
4
5
Table 7 – Pin Definitions
Pin
1
2
3
4
5
6
7
8
9
10
Unit
RxGND
RxVcc
SD
RD-
RD+
TxVcc
TxGND
TxDIS
TD+
TD-
Notes
Directly connect this pin to the receiver ground plane
+3.3V dc power for the receiver section
Active high on this indicates a received optical signal(LVTTL)
Receiver Data Out Bar(LVPECL)
Receiver Data Out (LVPECL)
+3.3V dc power for the transmitter section
Directly connect this pin to the tranmitter ground plane
Transmitter disable(LVTTL)
Transmitter Data In (LVPECL)
Transmitter Data In Bar (LVPECL)
-4-
DS-6363
Rev 0.1 2010-12-13
P/N: B-1x/1x-1250C-F(DFB)-SSCx-G5
1.25 Gbps bi-directional SC Receptacle
Single Fiber Transceiver
Recommended Circuit Schematic
PHY DEVICE
TERMINATE AT
TRANSCEIVER INPUTS
Vcc(+3.3V)
Z=50
Ω
TD-
100
Ω
LVPECL
Z=50
Ω
130
Ω
130
Ω
TD+
Tx Disable
LVTTL
10
TD-
9
TD+
8
TxDIS
7
TxGND
6
1
μ
H
TxVcc
C2
Vcc(+3.3V)
C3
Tx
RxGND
RxVcc
10
μ
F
Rx
RD+
RD-
SD
1
μ
H
C1
RD+
Vcc(+3.3V)
1
2
3
4
5
Z=50
Ω
100
Ω
LVPECL
RD-
Z=50
Ω
130
Ω
130
Ω
Z=50
Ω
Vcc(+3.3V)
SD
LVTTL
NOTE:C1=C2=C3=100nF
TERMINATE AT
DEVICE INPUTS
The split-loaded terminations for ECL signals need to be located at the input of devices receiving those ECL signals.
The power supply filtering is required for good EMI performance. Use short tracks from the inductor L1/L2 to the module Rx Vcc.
A GND plane under the module is required for good EMI and sensitivity performance.
-5-
DS-6363
Rev 0.1 2010-12-13
