M16C/6S Group

SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER

REJ03B0014-0501

Rev.5.01

Dec 10, 2009

Overview

The M16C/6S group are highly integrated single-chip microcomputers with PLC (Power Line Communica-

tion) modem core and AFE (Analog Front End) in a 64-pin plastic molded LQFP package, which incorpo-

rates IT800 PLC modem technology developed by Yitran Communications Ltd. M16C/60 Series CPU core

enables a high level of code efficiency and high-speed operation. In addition, the implementation of Yitran's

patented DCSK (Differential Code Shift Keying) spread spectrum modulation technique in the IT800 mo-

dem core enables extremely robust communication over the existing electrical wiring, with data rates up to

7.5Kbps. The M16C/6S complies with worldwide regulations (FCC part 15, ARIB and CENELEC bands)

and is suitable for a variety of narrowband applications like smart metering and home networking.

Applications

Power Line Communication

------Table of Contents------

Overview ......................................................... 1

Memory ......................................................... 10

Central Processing Unit (CPU) ..................... 11

SFR ............................................................... 13

Reset ............................................................. 19

Processor Mode ............................................ 23

Clock Generation Circuit ............................... 27

Protection ...................................................... 46

Interrupts ....................................................... 47

Watchdog Timer ............................................ 66

DMAC ........................................................... 68

Timers ........................................................... 78

Timer A ...................................................... 79

Serial I/O ....................................................... 92

Clock Synchronous serial I/O Mode ........ 101

UART Mode ............................................. 109

Special Mode ........................................... 117

SI/O3 and SI/O4 ...................................... 132

Programmable I/O Ports ............................. 137

Electrical Characteristics ............................. 149

Flash Memory Version ................................ 160

IT800AFE (Analog Front End) .................... 184

Usage Notes ............................................... 189

Appendix ..................................................... 199

Specifications written in this manual are believed to be accurate, but are

not guaranteed to be entirely free of error. Specifications in this manual

may be changed for functional or performance improvements. Please make

sure your manual is the latest edition.

Rev.5.01 Dec 10, 2009

REJ03B0014-0501

page 1 of 201

M16C/6S Group

Overview

IT800 PHY performance outline of M16C/6S group.

The IT800 PHY is a PLC optimized Physical Layer (PHY) which consists of IT800 modem core and internal

AFE (Analog Front End). The implementation of Yitran's patented DCSK spread spectrum modulation

technique in the IT800 modem core enables extremely robust communication over the existing electrical

wiring, with data rates up to 7.5Kbps. In addition to the inherent interference immunity provided by the

DCSK modulation, the IT800 PHY utilizes several mechanisms for enhanced communication robustness,

such as forward short block soft decoding error correction algorithm and special synchronization algo-

rithms.

The IT800PHY communicates M16C core with clock synchronous serial I/O, interrupt and input/output

ports in M16C/6S (Note). M16C/6S requires external AFE. Table 1.1.2 lists IT800 PHY performance outline

of M16C/6S group.

Table 1.1.2. IT800 PHY performance outline of M16C/6S group

Item

Features

Performance

High immunity to signal fading, various noise characteristics,

impedance modulation and phase/frequency distortion

High in-phase and cross-phase reliability

DCSK (Differential Code Shift Keying)*

*Yitran patented modulation technique

Forward short-block soft decoding error correction mechanism,

CRC-16

FCC, ARIB, EN50065-1-CENELEC

120-400 KHz

7.5Kbps Standard Mode (SM)

5.0Kbps Robust Mode (RM)

1.25Kbps Extremely Robust Mode (ERM)

A-Band (Outdoor): 20-80 KHz

B-Band (Indoor): 95-125 KHz

2.5 Kbps Robust Mode (RM)

0.625Kbps Extremely Robust Mode (ERM)

10bit-D/A converter, preamp,

1bit-A/D converter x 3 channels

Modulation Technique

Error Correction/Detection

Complies with W/W Regulations

Data Rate &

FCC & ARIB

Frequency Band

CENELEC

Internal AFE

Note:

Direct operation of IT800 PHY is not recommended. Since the Layer 2 (DLL) handles the channel access

procedure, using the IT800DLL as such assures coexistence with other IT800 technology based products,

regardless of the vendor, protocol and the application. There is NO such coexistence if the device is used

in direct operation of IT800 PHY. Note that the coexistence here is not with other technologies but with

other IT800 technology based products. As for details, please refer to the next section and Appendix.

About Firmware

Renesas recommends IT800DLL (Product name: D2DL) as a Data Link Layer (DLL) of M16C/6S group.

The IT800 DLL is a PLC optimized DLL especially for the products based on Yitran's IT800 technology. For

availability of IT800DLL, please contact Renesas technical support representative. For more details about

the IT800DLL advantages, please refer to Appendix.

Rev.5.01 Dec 10, 2009

REJ03B0014-0501

page 3 of 201
