FACTSHEET F-200-1
IDMD–28–S–12–G
.100"
(2,54mm)
IDC CABLE
Specifications:
IDSS, IDSD
Insulator Material:
Black Glass Filled Polyester
Temperature Range:
-65°C to +80°C
Contact:
BeCu
Plating:
Au over 50µ" (1,27µm) Ni or
Sn over 100µ" (2,54µm) Cu or
50µ" (1,27µm) Ni
Current Rating:
1A
Contact Resistance:
10 mΩ max
Lead Size Range:
(0,56mm) .022" SQ to
(0,71mm) .028" SQ
Lead Insertion Depth:
(5,59mm) .220" to (6,22mm)
.245"
Insertion Force:
4oz avg
((0,63mm) .025" SQ probe)
Withdrawal Force:
3oz avg
((0,63mm) .025" SQ probe)
Wire:
28 AWG 7/36 stranded
Tinned Copper
IDMS, IDMD, IDSS
& IDSD SERIES
NO. PINS
PER ROW
END
ASSEMBLY
Mates with:
TSW, MTSW, TSM
TYPE
STRIP
ROW
OPTION
IDM
= Standard Tail Male Plug
IDS
= Socket
–02 thru –32
S
= Single
D
= Double
(Color coded cable
N/A for 31 thru 36
pins/row. See
–G option.)
DOUBLE
Full size (64 positions):
(82,55) 3.250
Less than 64 positions:
No. Positions/row X (2,54) .100 + (1,68) .066
SINGLE
Full size (32 positions):
(81,53) 3.210
Less than 32 positions:
No. Positions/row X (2,54) .100 + (0,71) .028
–S
= End
IDMS
(Single)
(2,54)
.100
(6,10)
.240
MAX
(0,48)
.019
(3,18)
.125
(2,54)
.100
Single
Specifications:
IDMS, IDMD
Insulator Material:
Black Glass Filled Polyester
Temperature Range:
-65°C to +80°C
Terminal:
Phosphor Bronze
Plating:
Au over 50µ" (1,27µm) Ni or
Sn over 100µ" (2,54µm) Cu or
50µ" (1,27µm) Ni
Current Rating:
1A
Wire:
28 AWG 7/36 stranded
Tinned Copper
IDMD
(Double)
(5,08)
.200
Socket or Male Plug
on one end
(0,46)
.018
x
(0,48)
.019
(2,54)
.100
–D
= Double
End
–02 thru –36
DOUBLE
Full size (72 positions):
(91,71) 3.650
Less than 72 positions:
No. Positions/row X (2,54) .100 + (1,50) .059
SINGLE
Full size (32 positions):
(91,69) 3.610
Less than 36 positions:
No. Positions/row X (2,54) .100 + (0,48) .019
IDSS
(Single)
IDSD
(Double)
(5,08)
.200
Socket or Male Plug
on each end
–T
= End
Transfer
(9,27)
.365
REF
(2,54)
.100
Note:
This Series is non-standard,
non-returnable.
(0,76)
.030
SQ
(2,54)
.100
Male Plug on one end with
socket on other.
Begin part
number with IDM.
Due to technical progress, all designs, specifications and components are subject to change without notice.
SAMTEC USA
• Tel: 1-800-SAMTEC-9 or 812-944-6733 • Fax: 812-948-5047
SAMTEC UK
• Tel: 01236 739292 • Fax: 01236 727113
SAMTEC GERMANY
• Tel: +49 (0) 89 / 89460-0 • Fax: +49 (0) 89 / 89460-299
SAMTEC FRANCE
• Tel: 01 60 95 06 60 • Fax: 01 60 95 06 61
SAMTEC ITALY
• Tel: 39 039 6890337 • Fax: 39 039 6890315
SAMTEC ASIA PACIFIC
• Tel: 65-745-5955 • Fax: 65-841-1502
SAMTEC CHINA
• Tel: 86-21-5385-4089 • Fax: 86-21-5385-4047
SAMTEC JAPAN
• Tel: 81-424-42-8318 • Fax: 81-424-42-8319
SAMTEC TAIWAN
• Tel: (02) 2395-1677 • Fax: (02) 2395-1689
SAMTEC HONG KONG
• Tel: 852-26904858 • Fax: 852-26904842
IDSD–06–D–5–S–02
IDSD–29–S–5
ASSEMBLED
LENGTH
OPTION
ALSO AVAILABLE
Molded-To-Position
IDC Assembles
POLARIZING KEY
Assembled Length in
INCHES (±1/8" )
(2 inches minimum)
(0,64) .025
SQ
(5,84)
.230
Optional polarizing key for
use with IDSS & IDSD
Series. Also polarizes
SSW, SSQ, ESW & ESQ
Series. Black High
Temperature Thermoplastic
Order: Part Number PK-01-06
•
•
•
•
•
Low Profile
Skinny side locks
Dual beam contacts
Single and double row
Many common
sizes available
Call Samtec for
HCXX Series.
–T
= 150
µ
" (3,81
µ
m) Tin Plating
(Both ends)
(3,81
Tin
–C
= 150
µ
"(0,25
µµ
m)GoldIDM/
m)
IDS
10
µ
"
10
µ
" (0,25
µ
m) Gold IDM/
–ST “X”
= Stripped & Tinned
Specify Suffix from table. All
dimensions are
±
1
/
16
". Not available
in 28 positions and higher.
–S “XX”
= Daisy Chain Single
“XX” ±
1
⁄
8
"
2"
min.
Single Row
Connectors
(IDSS)
–R
= Reversed
–A
= 150
µ
" (3,81
µ
m) Tin IDS
Standard plating is selective
gold over BeCu contact for IDS;
Selective gold over phosphor
bronze for IDM.
Outer Most
4" minimum
1
–P “XX”
=Polarized
72
04
02
–ST8
–ST4
–ST2
–ST3
1/8" (3,18)
1/4" (6,35)
1/2" (12,70)
3/8" (9,53)
4
When mating double row
connector with two single row
connectors, the outer most
single will be connected to
Conductor #1 and the inside
single to Conductor #2.
8
–M
= Middle Reversed
7
–B “XX”
= Breakout
71
03
01
–D “XX”
= Daisy Chain, Double
“XX” ±
1
⁄
8
"
2"
min.
Double Row
Connectors
(IDSD or
IDMD)
Outer Most
“XX”
4" minimum
7
Specify “XX” as position. For
Double the same position will
be polarized on both ends. (Not
available on IDM or EDM,
unless Transfer, then only the
socket is polarized)
2
Specify “XX” as number of
conducts to be broken out.
Requires –SXX, –WXX or –DXX
8
–O
= Outside Reversed
–G
= Gray Cable
5"max.
2"min.
Breakout starts with Number 1
lead indicated by brown wire or
red stripe. Shown on top side.
–W “XX”
5
Specify –G for Gray cable.
Gray cable has one red edge.
IDSS uses .100" centerline
cable. IDSD and IDMD uses
.050" centerline cable. Cable is
28 AWG 7/36 copper wire.
Standard cable is same as
above except color coded.
= Wiring Reversed
Daisy Chain, Single
–RW
= Reversed Wiring
#1 wire opposite position #1.
3
6
Same as –S “XX” except outer
strip connected to Conductor
#2 and inside strip connected
to Conductor #1.
7
Requires –SXX, –WXX or –DXX
8
