MIL-DTL-32139 Nanominiature Connectors
Dual Row Metal Shell Pigtails (M32139/03 & /04)
How to Order
SECTION A
Basic Spec
M32139/
Note:
order
with
“GS”
prefix
until QPL
approval
is
issued.
GS32139/
03-A
03-B
03-C
03-D
03-E
03-F
03-G
04-A
04-B
04-C
04-D
04-E
04-F
04-G
–
–
–
–
–
–
–
–
–
–
–
–
–
–
Slash Number -
Insert Arrangement
9 Contacts
15 Contacts
21 Contacts
25 Contacts
31 Contacts
37 Contacts
51 Contacts
How To Order M32139 Dual Row Metal Shell Connectors
Shell Material
and Finish Space Class
C
Aluminum
Shell,Cadmium
Plated
Wire Type
(#30 AWG, 7 Strand Silver-Coated
Copper, Extruded PTFE Insulation,
250 V rms, 200º C.)
Hardware
S
Jackscrew,
#0-80, Hex Head
(Slash 01 Pin
Connectors Only)
Plugs
Pin Connector, 9 Contacts
Pin Connector, 15 Contacts
Pin Connector, 21 Contacts
Pin Connector, 25 Contacts
Pin Connector, 31 Contacts
Pin Connector, 37 Contacts
Pin Connector, 51 Contacts
Receptacles
Socket Connector, 9 Contacts
Socket Connector, 15 Contacts
Socket Connector, 21 Contacts
Socket Connector, 25 Contacts
Socket Connector, 31 Contacts
Socket Connector, 37 Contacts
Socket Connector, 51 Contacts
NEMA HP3-ETXBBB Wire
S
Space Class
01
02
03
04
05
06
–
–
–
–
–
–
6 Inches White
18 Inches White
36 Inches White
6 Inches 10 Color Repeat
18 Inches 10 Color Repeat
36 Inches 10 Color Repeat
T
Threaded Hole,
#0-80
(Slash 02 Socket
Connectors Only)
N
Aluminum Shell,
Electroless
Nickel Plated
(#30 AWG, 7 Strand Silver-Coated
High-Strength Copper, Extruded
Cross-Linked Modified ETFE
Insulation, 600 V rms, 200º C.)
M22759/33-30 Wire
S
Stainless
Steel Shell,
Passivated
(Not For Use
With Cadmium
Plated
Aluminum
Shells)
07
08
09
10
11
12
–
–
–
–
–
–
T
Titanuim Shell,
Unplated
Omit for
Non-Space
Applications
6 Inches White
18 Inches White
36 Inches White
6 Inches 10 Color Repeat
18 Inches 10 Color Repeat
36 Inches 10 Color Repeat
(#30 AWG, 7 Strand Silver-
Coated High-Strength Copper,
Tape-Wrapped Dual-wall Modified
ETFE/Polyimide Insulation, 600 V
rms, 200º C.)
Composite PTFE/
Polyimide Wire
13
14
15
16
17
18
–
–
–
–
–
–
6 Inches White
18 Inches White
36 Inches White
6 Inches 10 Color Repeat
18 Inches 10 Color Repeat
36 Inches 10 Color Repeat
Part Number Example
M32139/
© 2005 Glenair, Inc.
www.glenair.com
03-A
01
CAGE Code 06324/OCA77
S
N
S
Printed in U.S.A.
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
A-4
E-Mail: sales@glenair.com
