PRELIMINARY DATA SHEET
LASER DIODE
NX8560SJ Series
EA MODULATOR AND WAVELENGTH MONITOR INTEGRATED
1 550 nm MQW-DFB LASER DIODE MODULE
FOR 10 Gb/s APPLICATIONS
DESCRIPTION
The NX8560SJ Series is an Electro-Absorption (EA) modulator and
wavelength monitor integrated, 1 550 nm Multiple Quantum Well (MQW)
structured Distributed Feed-Back (DFB) laser diode module. It is capable of
transmitting up to 40 km standard single mode fiber (dispersion: 800 ps/nm)
for 10 Gb/s applications with built in wavelength monitor.
FEATURES
• Integrated electroabsorption modulator
• Wavelength monitor function (Etalon filter, Wavelength monitor PD)
• 10 Gb/s transmission up to 40 km SSMF (dispersion: 800 ps/nm)
• 7-pin butterfly package with GPO
TM
connector
• Available for DWDM wavelengths based on ITU-T recommendations
(50 GHz grid, refer to
ORDERING INFORMATION)
The information in this document is subject to change without notice. Before using this document, please confirm that
this is the latest version.
Not all devices/types available in every country. Please check with local NEC Compound Semiconductor Devices
representative for availability and additional information.
Document No. PL10184EJ01V0DS (1st edition)
Date Published May 2003 CP(K)
Printed in Japan
©
NEC Compound Semiconductor Devices 2003
