BIAS TEES
2.4mm, 50 kHz - 50 GHz, 25 Volts / 150 mA
SPECIFICATIONS:
Models: 8810EMFX-50, 8810EFFX-50, 8810EMMX-50, 8810EFMX-50
Electrical:
Frequency Range
VSWR:
Insertion Loss:
100 kHz
50 kHz - 18 GHz
18 - 40 GHz
40 - 50 GHz
Impedance
Isolation (RF to Bias Port):
250 kHz - 26 GHz
100 kHz - 50 GHz
DC Voltage
DC Current
Rise Time (10% - 90%)
50 kHz - 50 GHz
1.80:1 Max.
Typical performance from 50 kHz - 50 GHz
Insertion Loss (dB)
0.5dB Typical
1.5dB Max.
3.0dB Max.
3.0dB Typ.; 4.0dB Max.
50 Ohms
50dB Typical
30dB Typ.
25 VDC Max.
150 mA Max.
< 9 pS Typical
Passivated Stainless Steel
Gold Plated Beryllium Copper
Aluminum with Chemical Conv. Coating
or Gold Plated Brass
Passivated Stainless Steel
Nickel Plated Brass
0
-1.0
-2.0
-3.0
-4.0
-5.0
.00001 .0001
.001
.01
.1
FREQ (GHz)
1
10
100
50
Mechanical:
2.4mm Connectors
Conductors
Housing
SMA Connectors
Mates with MIL-STD-348
Mates with 1.85mm & V* Connectors
VSWR
3.50
3.00
2.50
2.00
1.50
1.00
.00001 .0001
.001
.01
2.00
1.50
1.00
100
50
BNC Connectors
Mates with MIL-STD-348
.1
FREQ (GHz)
1
10
*V is a trademark of Anritsu Corp.
.25 [6.35]
.515±.030
[13.08±0.76]
DC Input Connector Options
Solder Post, X=1
BNC Female, X=3
.244
[6.20]
.489 [12.42]
Centered
DC Input
(SMA Female
Connector shown)
Option X = 2
3X Ø.102 [Ø2.59]
THRU
Connector
Overall
Configuration Port
Length
AC + DC
AC
Max.
Male
Female 1.63 [41.40]
8810EMFX-YY
Model
Numbers
1.060
[26.92]
Cent.
AC + DC
Port
1.20
[30.48]
AC Port
8810EFFX-YY
8810EMMX-YY
8810EFMX-YY
Female
Male
Female
Female 1.60 [40.64]
Male 1.75 [44.45]
Male
1.63 [41.40]
.19 [4.83]
Overall
Length
.63 [16.00]
HOW TO ORDER:
Model Number:
8810EYYX-50
Base Number
DC Connector Type
1 = Solder Post
2 = SMA Female Conn.
3 = BNC Female Conn.
Ordering Examples:
Model Number:
8810EFF2-50
50 KHz - 50 GHz, 2.4mm Fem/Fem
SMA Female DC Connector Type
Model Number:
8810EMF1-50
50 KHz - 50 GHz, 2.4mm Male/Fem
Solder Post DC Connector Type
8810E: REV P
Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.
Design specifications are subject to change without notice.
Contact factory for technical specifications before purchasing or use.
Aeroflex / Inmet, Inc.
• 300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.
888-244-6638 or 734-426-5553 • FAX: 734-426-5557
www.aeroflex.com/inmet • inmetsales@aeroflex.com
