TTE11AGPC3TES Product Details
Live Product Chat
Toggle Switches
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
TTE11AGPC3TES
(8-1437562-5)
T E I nternal N umber: 8 - 1 4 3 7 5 6 2 - 5
Product Highlights:
l
TT (Tiny) Series
l
Single Pole - Single Throw C onfiguration (Pole-Throw)
l
C urrent Rating = 0.4 VA Amps.
l
Mount Style = Through-Hole
l
Termination Type = Printed C ircuit, Vertical
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
ALC OSWITC H PRODUC TS
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
C onfiguration (Pole-Throw) = Single Pole - Single Throw
l
Termination Type = Printed C ircuit, Vertical
Electrical Characteristics:
l
C urrent Rating (Amps.) = 0.4 VA
Termination Related Features:
l
Seal Type = Terminal Seal (epoxy), Internal Actuator "O" Ring
Body Related Features:
l
Series = TT (Tiny)
l
Mount Style = Through-Hole
Contact Related Features:
l
C ontact Plating = Gold over Nickel
Housing Related Features:
l
Toggle Style = Baton Long
l
Toggle Length (mm [in]) = 9.40 [0.370]
l
Process Sealed = Yes
l
Bushing Style = Threaded
l
Bushing Type = 10-48
Configuration Related Features:
l
Operating Function
= On None Off
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
Other:
l
Brand = Alcoswitch
Additional Information:
l
Product Line Information
Additional Product Images:
l
Dimensional Drawing
