A02AG-5NS-BQ

Description
Active Delay Line, 2-Func, True Output, PDSO14, SOP-14
Categorylogic    logic
File Size42KB,1 Pages
ManufacturerRCD Components Inc.
Websitehttp://www.rcdcomponents.com/
Download Datasheet Parametric View All

A02AG-5NS-BQ Overview

Active Delay Line, 2-Func, True Output, PDSO14, SOP-14

A02AG-5NS-BQ Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
Parts packaging codeSOIC
package instructionSOP,
Contacts14
Reach Compliance Codecompliant
series02
JESD-30 codeR-PDSO-G14
JESD-609 codee0
Logic integrated circuit typeACTIVE DELAY LINE
Number of functions2
Number of terminals14
Maximum operating temperature70 °C
Minimum operating temperature
Output polarityTRUE
Package body materialPLASTIC/EPOXY
encapsulated codeSOP
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
programmable delay lineNO
Certification statusNot Qualified
Nominal supply voltage (Vsup)5 V
surface mountYES
Temperature levelCOMMERCIAL
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formGULL WING
Terminal pitch2.54 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Total delay nominal (td)5 ns
width7.24 mm
Base Number Matches1
ACTIVE (DIGITAL) DELAY LINES
SINGLE, DUAL, TRIPLE, QUAD DELAYS
RESISTORS CAPACITORS COILS DELAY LINES
A0 SERIES
RoHS
Term.W
is Pb-free
and RoHS
compliant
RCD
A03AG
1 50NS
1
RCD
A04AG
100NS
Economical cost, prompt delivery!
Wide range of values, 5nS to 500nS
TTL schottky interfaced
Low cost solution for multiple timing delays in a single package!
RCD’s digital delay lines have been designed to provide precise fixed delays with all
the necessary drive and pick-off circuitry. All inputs and outputs are schottky-type and
require no additional components to achieve specified delays. Designed to meet
the applicable environmental requirements of MIL-D-23859. Type A01 features a
single fixed delay, type A02 features two isolated delays, A03 features three delays,
and A04 features 4 delays (single delay SIP available). Application Guide available.
OPTIONS
Opt.T= trailing edge design
Opt. F =fast TTL, H =HCMOS, C =FACT
Opt.A = auto-insertable design
Opt.39 = -40 to +85°C operating temp.
Tighter tolerances, faster rise times
Low power design
Military screening
PACKAGE STYLES
.500 [12.7]
Max
.015 [.4]
SIDE VIEW
SIDE
.40 [10.2]Max
.500 [12.7]
Max
8
5
.
295 [7.5]
Max.
.285 [7.24]
TOP VIEW
.300±.01
[7.6±.25]
1
4
STANDARD DELAY TIMES
5nS, 10nS, 15nS, 20nS. 25nS, 50nS,
75nS, 100nS, 250nS, 500nS
Intermediate values available on special order.
.300 ±.01
[7.62±.25]
.120 [3] Min
←.
100 [2.54]
.250
[6.35]
.300 [7.6]
.420 [10.67]
.020 [.5] .10 [2.54]
→ ←
PACKAGE STYLE 8P (8-Pin DIP)
PACKAGE STYLE 8SM (8-Pin SM DIP)
14
SPECIFICATIONS
Operating Temp: 0 to 70°C
Delay Tol: ±2nS or ±5%, whichever greater
Rise Time: 4nS
Peak Soldering Temp: +230°C
.800 [20.3] Max.
SIDE VIEW
.
295 [7.5]
Max.
.40
[10.2]Max
.800 [20.3] Max
8
.285 [7.24]
TOP VIEW
1
7
.120 [3] Min
.300
[7.6]
.300 [7.6]
.420 [10.67]
.015 [.4]
.600 ± .010
[15.2 ± .25]
←.
100 [2.54]
.300±.01
[7.6±.25]
.020 [.5]
→ ←
.10 [2.54]
CHARACTERISTICS
RCD
Type
A 01
A 01S
A 01A G
A 02A
A 02S A
A 02A G
A 03
A 03S
A 03A G
A 03S A G
A 04
A 04A G
Independent
Delays
Single
Single
Single
Dual
Dual
Dual
Triple
Triple
Triple
Triple
Quadruple
Quadruple
P a cka g e
Style
14P
8P
14S M
8S M
14P
8P
14S M
8S M
14P
8P
14S M
8S M
14P
14S M
Circuit
A
B
A
B
C
D
C
D
E
F
E
F
G
G
PACKAGE STYLE 14P (14-Pin DIP)
PACKAGE STYLE 14SM (14-Pin SM DIP)
CIRCUIT SCHEMATICS
Circuit A
14
(VCC)
8
(OUT)
Circuit B
8
(VCC)
5
(OUT)
Circuit C
14
(VCC)
12
(OUT)
8
(OUT)
Circuit D
8
(VCC)
7
(OUT)
5
(OUT)
A01SAG Single
DELAY
DELAY
DELAY
DELAY
DELAY DELAY
1
(IN)
7
(GND)
1
(IN)
4
(GND)
1
(IN)
5
(IN)
7
(GND)
1
(IN)
3
(IN)
4
(GND)
A02SAG Dual
Circuit E
14
(VCC)
12
(OUT)
10
(OUT)
8
(OUT)
Circuit F
8
(VCC)
7
(OUT)
6
(OUT)
5
(OUT)
Circuit G
14
(Vcc)
12
(OUT)
10
(OUT)
9
(OUT)
8
(OUT)
DELAY
DELAY
DELAY
DELAY DELAY DELAY
DELAY
DELAY DELAY DELAY
1
(IN)
3
(IN)
5
(IN)
7
(GND)
1
(IN)
2
(IN)
3
(IN)
4
(GND)
1
(IN)
3
(IN)
4
(IN)
5
(IN)
7
(GND)
TEST CONDITIONS @25°C
1.) Input test pulse voltage: 3.2V
2.) Input pulse width: 50nS or 1.2x the total
delay (whichever is greater)
3.) Input rise time: 2.0nS (0.75V to 2.4V)
4.) Delay measured at 1.5V on leading edge
only with no loads on output (specify opt. T
for trailing edge design)
5.) Supply Voltage (Vcc): 5V
6.) Pulse spacing: 2x pulse width minimum
P/N DESIGNATION:
A01A
Type:
A01, A01S, A01AG, etc.
Options:
T, H, F, C, A, 39 (leave blank if std.)
Delay Time:
5nS, 10nS, etc
Packaging:
B=Bulk (Magazine tube is standard)
Termination:
W= Lead-free, Q= Tin/Lead
(leave blank if either is acceptable)
- 100nS - B W
RCD Components Inc,
520 E.Industrial Park Dr, Manchester, NH, USA 03109
rcdcomponents.com
Tel: 603
-
669
-
0054 Fax: 603
-
669
-
5455 Email:sales@rcdcomponents.com
FA077 Sale of this product is in accordance with GF-061. Specifications subject to change without notice.
