AL Series - Thin Film Chip Inductor
Features
－A
Photo Lithographic Single Layer Ceramic Chip
－High
SRF, Excellent Q, Superior Temperature Stability
－Tight
Tolerance of ± 1% or ± 0.1nH
－Self
Resonant Frequency Controlled within 10%
－Stable
Inductance in High Frequency Circuit
－Highly
Stable Design for Critical Needs
－Products
with Pb-free Terminations Meet RoHS Requirements
Applications
－Cellular
Telephone, Pagers and GPS Products
－VCO,TCXO
Circuit and RF Transceiver Module
－Wireless
LAN, Bluetooth Module , Communication Appliances
Construction
How
to Order
How to Order
AL
SEI Type
02
Dimensions
(LxW)
G
Inductance Tolerance
T
Packaging
10N
Inductance
Type
AL
Codes Dimensions (LxW) EIA
AL03
AL02
1.6 x 0.8 mm
1.0 x 0.5 mm
0603
0402
Codes
J
H
G
F
S
C
B
Type
±
5%
± 3%
±
2%
±
1%
±
0.3nH
±
0.2nH
±
0.1nH
Codes
T
Type
Tape and Reel
Codes
1N0
10N
R10
Type
1.0nH
10nH
100nH
20N8 20.8nH
Toll Free: (888) SEI-SEIS
www.seielect.com
1
email: marketing@seielect.com
AL Series - Thin Film Chip Inductor
Dimensions
Unit: mm
Codes
AL03
AL02
A
1.6±0.10
1.0±0.05
B
0.8±0.10
0.5±0.05
C
0.45±0.10
0.32±0.05
D
0.3±0.20
0.2±0.10
C
D
D B
A
Standard
Electrical Specifications
0603
Chip Inductors
Inductance
(nH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
100
Tolerance
(% or nH)
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
Quality
Factor
/min.
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
15 / 300MHz
Resistance
DC/Max
(Ohm)
0.35
0.35
0.35
0.35
0.35
0.45
0.45
0.45
0.55
0.65
0.75
0.95
0.95
1.05
1.35
1.65
1.95
2.35
2.75
3.00
3.00
5.00
5.00
7.50
Current
DC/Max
(mA)
800
800
800
300
300
300
300
300
300
300
300
300
300
300
300
300
250
250
250
200
200
150
150
100
Self Resonant
Frequency/min.
(GHz)
13
13
10
10
8
6
6
6
5
5
5
4
4
3
3
2
2
2
1.5
1.5
1.5
1
1
1
Test Equipment: HP4286A+Agilent 16196A
Toll Free: (888) SEI-SEIS
www.seielect.com
2
email: marketing@seielect.com
AL Series - Thin Film Chip Inductor
Standard
Electrical Specifications
0402
Chip Inductors
Resistance
DC/Max
(Ohm)
0.10
0.10
0.15
0.15
0.15
0.25
0.25
0.25
0.35
0.35
0.35
0.45
0.45
0.55
0.55
0.65
0.85
0.85
1.05
1.05
1.25
1.25
1.25
1.35
1.55
1.75
1.75
1.95
2.15
2.55
2.65
3.25
3.75
Current
DC/Max
(mA)
800
800
700
700
700
700
560
560
560
440
440
380
380
380
340
320
280
280
260
260
220
220
220
200
180
180
130
100
100
90
90
75
75
Self Resonant
Frequency/min.
(GHz)
14
14
14
12
12
10
10
10
8
8
8
6
6
6
6
6
6
6
6
6
5.5
5.5
5.5
4.5
3.7
3.7
3.3
3.1
3.1
2.8
2.8
2.5
2.5
Inductance
(nH)
0.2
0.4
0.8
1.0
1.2
1.5
1.6
1.8
2.0
2.2
2.7
3.1
3.3
3.6
3.9
4.7
5.6
5.9
6.8
7.2
8.0
8.2
9.1
10
12
13.8
15
17
18
20.8
22
27
33
Tolerance
(% or nH)
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
0.1/0.2/0.3nH
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
1/2/3/5%
Quality Factor
/min.
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
13 / 500MHz
Test Equipment: HP4286A+Agilent 16196B
Toll Free: (888) SEI-SEIS
www.seielect.com
3
email: marketing@seielect.com
AL Series - Thin Film Chip Inductor
Inductor
Electrical Characteristics-0603 Series
AL03B T1N0
5
120
5
AL03B T1N2
50
40
Inductance (nH)
4
Inductance (nH)
4
3
2
1
0
10
100
1000
Q
2
1
0
10
100
1000
40
20
10
0
10000
0
10000
Frequency (MHz)
Frequency (MHz)
AL03B T1N5
5
50
AL03B T1N8
5
60
50
40
30
2
1
0
10
100
1000
20
10
0
10000
Inductance (nH)
4
3
2
1
0
10
100
1000
40
Inductance (nH)
4
3
Q
30
20
10
0
10000
Frequency (MHz)
Frequency (MHz)
AL03B T2N2
5
80
60
40
2
1
0
10
100
1000
20
0
10000
15
AL03B T2N7
60
40
Inductance (nH)
4
3
Inductance (nH)
10
Q
5
0
10
100
1000
20
0
10000
Frequency (MHz)
Frequency (MHz)
AL03B T3N3
40
60
250
AL03B T3N9
60
40
20
0
10000
Inductance (nH)
Inductance (nH)
30
20
10
0
10
100
1000
200
40
Q
20
100
50
0
10
100
1000
0
10000
Frequency (MHz)
Frequency (MHz)
Toll Free: (888) SEI-SEIS
www.seielect.com
4
email: marketing@seielect.com
Q
150
Q
Q
Q
3
80
30
AL Series - Thin Film Chip Inductor
Inductor
Electrical Characteristics-0603 Series
AL03B T4N7
200
60
200
AL03B T5N6
60
40
Inductance (nH)
Inductance (nH)
150
100
50
0
10
100
1000
40
150
100
50
0
10
100
1000
20
0
10000
20
0
10000
Frequency (MHz)
Frequency (MHz)
AL03B T6N8
200
60
250
AL03B T8N2
100
Inductance (nH)
Inductance (nH)
150
100
50
0
10
100
1000
200
40
Q
20
0
10000
100
50
0
10
100
1000
20
-20
10000
Frequency (MHz)
Frequency (MHz)
AL03B T10N
AL03GT10N
240
50
40
AL03B T12N
AL03GT12N
300
240
180
120
60
0
10
100
1000
40
35
30
25
20
15
10
5
0
10000
Inductance (nH)
180
120
Q
30
20
60
0
10
100
1000
10
0
10000
Inductance (nH)
Frequency (MHz)
Frequency (MHz)
AL03B T15N
AL03GT15N
500
60
AL03B T18N
AL03GT18N
500
45
30
15
0
10000
Inductance (nH)
Inductance (nH)
400
400
Q
200
100
0
10
100
1000
20
0
10000
200
100
0
10
100
1000
Frequency (MHz)
Frequency (MHz)
Toll Free: (888) SEI-SEIS
www.seielect.com
5
email: marketing@seielect.com
Q
300
40
300
Q
Q
150
60
Q
Q
