Datasheet> All Categories > Discrete semiconductor> diode> BR38

Preview

BR38: DescriptionBridge Rectifier Diode, 1 Phase, 3A, 800V V(RRM), Silicon, ROHS COMPLIANT, PLASTIC, BR-3, 4 PIN; CategoryDiscrete semiconductor diode; File Size207KB，2 Pages; ManufacturerRectron Semiconductor; Websitehttp://www.rectron.com/; Environmental Compliance

Download Datasheet Parametric View All

BR38 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BR38	-	-	View	Buy Now

BR38 Overview

Bridge Rectifier Diode, 1 Phase, 3A, 800V V(RRM), Silicon, ROHS COMPLIANT, PLASTIC, BR-3, 4 PIN

BR38 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	S-PUFM-W4
Contacts	4
Reach Compliance Code	not_compliant
Other features	UL RECOGNIZED
Minimum breakdown voltage	800 V
Shell connection	ISOLATED
Configuration	BRIDGE, 4 ELEMENTS
Diode component materials	SILICON
Diode type	BRIDGE RECTIFIER DIODE
Maximum forward voltage (VF)	1 V
JESD-30 code	S-PUFM-W4
JESD-609 code	e3
Maximum non-repetitive peak forward current	50 A
Number of components	4
Phase	1
Number of terminals	4
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Maximum output current	3 A
Package body material	PLASTIC/EPOXY
Package shape	SQUARE
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	265
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	800 V
Maximum reverse current	0.00001 µA
surface mount	NO
Terminal surface	Matte Tin (Sn)
Terminal form	WIRE
Terminal location	UPPER
Maximum time at peak reflow temperature	10
Base Number Matches	1

Preview

Download Datasheet

View All

RECTRON

SEMICONDUCTOR

TECHNICAL SPECIFICATION

BR305

THRU

BR310

SINGLE-PHASE SILICON BRIDGE RECTIFIER

VOLTAGE RANGE 50 to 1000 Volts CURRENT 3.0 Amperes

FEATURES

*

Surge overloab rating: 50 amperes peak

Low forward voltage drop

Small size: simple installation

Silver-plated copper leads

Mounting position: Any

Mounting: Hole thru for # 6 screw

Weight: 3.36 grams

BR-3

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25

o

C ambient temperature unless otherwise specified.

Single phase, half wave, 60 Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

Dimensions in inches and (millimeters)

MAXIMUM RATINGS

(At T

A

= 25

o

C unless otherwise noted)

RATINGS

Maximum Recurrent Peak Reverse Voltage

Maximum RMS Bridge Input Voltage

Maximum DC Blocking Voltage

Maximum Average Forward Rectified Output Current at Tc = 50 C

Peak Forward Surge Current 8.3 ms single half sine-wave

superimposed on rated load (JEDEC method)

Operating Temperature Range

Storage Temperature Range

T

J

T

STG

-55 to + 125

-55 to + 150

0

o

SYMBOL

V

RRM

V

RMS

V

DC

I

O

I

FSM

BR305

50

35

50

BR31

100

70

100

BR32

200

140

200

BR34

400

280

400

3.0

50

BR36

600

420

600

BR38

800

560

800

BR310

1000

700

1000

UNITS

Volts

Amps

C

ELECTRICAL CHARACTERISTICS

(At T

A

= 25

o

C unless otherwise noted)

CHARACTERISTICS

Maximum Forward Voltage Drop per element at 1.5A DC

Maximum Reverse Current at Rated

DC Blocking Voltage per element

@T

A

= 25 C

@T

C

= 100 C

o

SYMBOL

V

F

I

R

BR305

BR31

BR32

BR34

1.0

10

0.1

BR36

BR38

BR310

UNITS

Volts

uAmps

mAmps

1998-8
