Chokes for Data and Signal Lines
I Core Choke, EIA 1812
B82789***H
Rated voltage 42 V /80V-
Rated inductance 11 to 100 H
Rated current 150 to 300 mA
Construction
Current-compensated double choke with ferrite I core
Bifilar winding (B82789C0...)
Sector winding (B82789S0...)
Features
Suitable for reflow soldering
For gold-plated terminals conductive adhesion possible
Function
B82789C0:
Suppression of asymmetrical interference coupled in on lines
whereas data signals up to some MHz can pass unaffectedly
B82789S0:
Supression of asymmetrical (by L
R
) and symmetrical inteference (by L
S
)
coupled in on lines. The high-frequency portions of the symmetrical data
signal are decreased so far that EMC problems can be significantly reduced
Applications
Automotive applications, e.g. CAN-Bus
Industrial automation
Telecommunications
Terminals
Two versions: Gold plated and lead free tinned
Marking
Marking on component:
Manufacturer, bifilar or sector winding (coded), L value (in nH),
date of manufacture (coded)
Minimum data on reel:
Manufacturer, part number, ordering code, L value (in nH),
quantity, date of packing
Delivery mode
12-mm blister tape, reel packing (330-mm Ø reel), packing unit: 2500 pcs
Taping to IEC 60286-3. For details on taping and packing refer to data book
“Chokes and Inductors”, page 302
¢
¢
¢
¢
¢
¢
¢
¢
¢
¢
¢
¡
The information contained in this data sheet describes the
type of component and shall not be considered as guaran-
teed characteristics.
1
B82789-***-H*-1-7659
7 Pages
27.04.2004
Chokes for Data and Signal Lines
I Core Choke, EIA 1812
B82789***H
General technical data
£
Rated voltage V
R
Rated current I
R
Rated inductance L
R
Inductance tolerance
Stray inductance L
S
Inductance decrease
∆L/L
DC-resistance R
max
Solderability
42 V (50/60 Hz)
80 V-
Referred to 50 Hz and 110°C ambient temperature
Measured with HP 4284A at 100kHz, 0,1mA
-30/ +50%
Measured with HP 4284A at 100 kHz and 5 mA
<10% at dc magnetic bias with I
R
Measured at 20
°C
ambient temperature
(235
3)
°C
, (2
0,3) s
wetting of soldering area 95 %
in accordance with IEC 60068-2-58
250V-, 2s
55/150/56 (-55°C/+150°C/ 56 days damp heat test)
in accordance with DIN EN 60068-1
approx. 0,16 g
¥
¤
¤
Test voltage
Climatic category
Weight
11
22
22
51
100
0,06
0,1
3,0
0,10
0,25
300
250
250
250
150
250
580
580
550
1500
The information contained in this data sheet describes the
type of component and shall not be considered as guaran-
teed characteristics.
§
¦
L
R
H
¦
L
S, typ
H
I
R
mA
R
max
m
Ordering code
gold-plated terminals
B82789C0113H001
B82789C0223H001
B82789S0223H001
B82789C0513H001
B82789C0104H001
tinned terminals
B82789C0113H002
B82789C0223H002
B82789S0223H002
B82789C0513H002
B82789C0104H002
2
B82789-***-H*-1-7659
7 Pages
27.04.2004
Chokes for Data and Signal Lines
I Core Choke, EIA 1812
B82789***H
Current derating
I
OP
/I
R
versus ambient Temperature T
A
= 110 C
1,2
I
OP
/I
R
1
0,8
0,6
0,4
0,2
0
0
20 40 60 80 100 120 140 160
C
T
A
¨
The information contained in this data sheet describes the
type of component and shall not be considered as guaran-
teed characteristics.
4
¨
B82789-***-H*-1-7659
7 Pages
27.04.2004
Chokes for Data and Signal Lines
I Core Choke, EIA 1812
B82789***H
symmmetrical, both lines in series (differential mode)
B82789C0113H00*
50
dB
40
a
e
30
20
10
0
-2
10
10
-1
10
0
B82789C0223H00*
50
dB
40
a
e
30
20
10
0
-2
10
10
-1
10
0
The information contained in this data sheet describes the
type of component and shall not be considered as guaran-
teed characteristics.
B82793S0334N215
5
©
Insertion loss
e
( typical values at Z = 50 )
asymmmetrical, both lines in parallel (common mode)
10
1
10
2
MHz 10
3
f
10
1
10
2
MHz 10
3
f
B82789-***-H*-1-7659
7 Pages
27.04.2004
