SAW Components
SAW RF filter
Digital radio
Series/type:
Ordering code:
Date:
Version:
B1644
B39232B1644U510
May 29, 2013
2.7
EPCOS AG 2015. Reproduction, publication and dissemination of this publication, enclosures hereto and the information
contained therein without EPCOS' prior express consent is prohibited.
EPCOS AG is a TDK Group Company.
SAW Components
SAW RF filter
Data sheet
Application
s
s
s
s
s
s
B1644
2338.75 MHz
Low-loss RF filter for digital radio
Impedance transformation from 50
Ω
to 100
Ω
Unbalanced to balanced operation
Very low insertion attenuation
Low amplitude ripple
Usable passband 12.5 MHz
Features
s
s
s
s
s
s
s
s
s
Package size 3.0 x3.0 x 1.1 mm
3
Package code DCC6D
RoHS compatible
Approximate weight 0.037 g
Package for
Surface Mount Technology
(SMT)
Ni, gold-plated terminals
Lead free soldering compatible with J - STD20C
AEC-Q200 qualified component family
Electrostatic Sensitive Device
(ESD)
Pin configuration
s
2
s
4,6
s
1,3,5
Input
Output, balanced
To be grounded
4
2
1,3,5
6
Please read
cautions and warnings and
important notes
at the end of this document.
2
May 29, 2013
SAW Components
SAW RF filter
Data sheet
Characteristics
Temperature range for specification:
Terminating source impedance:
Terminating load impedance:
T = –20 ˚C to +85 ˚C
Z
S
=
50
Ω
Z
L
= 100
Ω
(balanced)
min.
Nominal frequency
Maximum insertion attenuation
2332.5 ... 2345.0
Amplitude ripple
(p-p)
2332.5 ... 2345.0
f
N
α
max
MHz
∆α
MHz
—
0.4
1.6
—
2.4
3.5
—
typ.
@ 25 ˚C
2338.75
max.
—
B1644
2338.75 MHz
MHz
dB
dB
Output amplitude balance
(|S
31
/S
21
|)
2332.5 ... 2345.0 MHz
Output phase balance
(φ(S
31
) –
φ(S
21
)+180˚)
2332.5 ... 2345.0 MHz
Return loss
Attenuation
88.0
880.0
1710.0
... 108.0
... 960.0
... 1910.0
2305.0
2310.0
2315.0
2320.0
2450.0
3060.0
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
α
–1.2
-0.7/0.0
1.5
dB
–9.0
10.0
-7.0/-1.8
15.0
1.0
—
˚
dB
50
40
38
—
—
—
—
20
35
65
56
43
11
9
9
6
25
50
—
—
—
—
—
—
—
—
—
dB
dB
dB
dB
dB
dB
dB
dB
dB
Group delay ripple
(p-p)
2332.5 ... 2345.0
MHz
—
3
15
ns
Please read
cautions and warnings and
important notes
at the end of this document.
3
May 29, 2013
SAW Components
SAW RF filter
Data sheet
Characteristics
Temperature range for specification:
Terminating source impedance:
Terminating load impedance:
T = –40 ˚C to+105 ˚C
Z
S
=
50
Ω
Z
L
= 100
Ω
(balanced)
min.
Nominal frequency
Maximum insertion attenuation
2332.5 ... 2345.0
Amplitude ripple
(p-p)
2332.5 ... 2345.0
f
N
α
max
MHz
∆α
MHz
—
0.4
2.9
—
2.4
4.8
—
typ.
@ 25 ˚C
2338.75
max.
—
B1644
2338.75 MHz
MHz
dB
dB
Output amplitude balance
(|S
31
/S
21
|)
2332.5 ... 2345.0 MHz
Output phase balance
(φ(S
31
) –
φ(S
21
)+180˚)
2332.5 ... 2345.0 MHz
Return loss
Attenuation
88.0
880.0
1710.0
... 108.0
... 960.0
... 1910.0
2305.0
2310.0
2315.0
2320.0
2450.0
3060.0
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
α
–5.0
-0.7/0.0
3.5
dB
–12.0
10.0
-7.0/-1.8
15.0
8.0
—
˚
dB
50
40
38
—
—
—
—
20
35
65
56
43
11
9
9
6
25
50
—
—
—
—
—
—
—
—
—
dB
dB
dB
dB
dB
dB
dB
dB
dB
Group delay ripple
(p-p)
2332.5 ... 2345.0
MHz
—
3
20
ns
Please read
cautions and warnings and
important notes
at the end of this document.
4
May 29, 2013
SAW Components
SAW RF filter
Data sheet
B1644
2338.75 MHz
Maximum ratings
Operable temperature range T
Storage temperature range
DC voltage
ESD voltage
Input power at
2332.5 MHz...2345.0 MHz
1)
2)
–45/+125 ˚C
–45/+125 ˚C
6
V
50
1)
V
200
2)
0
V
dBm
T
stg
V
DC
V
ESD
V
ESD
P
IN
machine model, 10 pulses
human body model, 1 pulse
source impedance 50
Ω
according to JESD22-A115B, 50V, Machine Model, 10 negative & 10 positive pulses.
acc. to JESD22-A114F (human body model), 1 negative & 1 positive pulse.
Transfer function
Please read
cautions and warnings and
important notes
at the end of this document.
5
May 29, 2013
