Chokes for power lines
I core double chokes
B82523T
Impedance |Z|
versus frequency f
10
5
Ω
|Z|
10
4
B82523T
IND0465-A
Current derating I
op
/I
R
versus ambient temperature T
A
1.4
I
op
I
R
1.2
1.0
0.8
IND0373-A
10
3
0.6
10
2
10
1 4
10
0.5 A
1A
2A
4A
6A
10 A
10
5
10
6
10
7
Hz 10
8
f
0.4
0.2
0
0
20
40
60
80
100
˚C 140
T
A
Cautions and Warnings
Current derating
At ambient temperatures above the operating temperature stated in the data sheet, the operating
current must be reduced according to the derating curve.
Potting
The following points must be observed if the components are potted:
– it is necessary to check whether the potting material used attacks or destroys the wire insulation.
– the effect of the potting material can change the high-frequency behaviour of the components.
Validation of the components
Even for customer-specific products, conclusive validation of the components in the circuit can only
be carried out by the customer.
Please read
Cautions and warnings
and
Important notes
at the end of this document.
4
12/05
