BJ77TL: DescriptionPANEL MOUNT, FEMALE, TNC, TRIAXIAL CONNECTOR, SOLDER, JACK; CategoryThe connector The connector; File Size69KB，1 Pages; ManufacturerVertiv

Download Datasheet Parametric View All

BJ77TL Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BJ77TL	-	-	View	Buy Now

BJ77TL Overview

PANEL MOUNT, FEMALE, TNC, TRIAXIAL CONNECTOR, SOLDER, JACK

BJ77TL Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	STANDARD:MIL-C-49142
Body/casing type	JACK
Characteristic impedance	50 Ω
Connector type	RF TRIAXIAL-TNC CONNECTOR
Contact point gender	FEMALE
Coupling type	THREADED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
insulator material	POLYTETRAFLUORO ETHYLENE
MIL compliance	NO
Installation method	STRAIGHT
Maximum operating frequency	0.5 GHz
Options	GENERAL PURPOSE
Panel mounting	YES
Termination type	SOLDER
Base Number Matches	1

Preview

Download Datasheet

View All

DWG NO.

SH

CUSTOMER

CUSTOMER P/N

CUST. REV

305-0508

REVISIONS

DESCRIPTIONS

DATE

APPROVED

1

DATA CONTAINED IN THIS DOCUMENT IS PROPRIETARY

REV

TO EMERSON CONNECTIVITY SOLUTIONS AND SHALL NOT

BE DISCLOSED, COPIED OR USED FOR PROCUMENT OR

MANUFACTURE WITHOUT EXPRESS WRITTEN PERMISSION

K

ECO 52831

12/20/10

T.KOHLER

.500 HEX NUT

.4375-28UNEF-2A

SOLDER POT ACCEPTS

.036 CONDUCTOR

.892 .015

.562

.380

.600

.062

.487

.190

.187

1.12 .030

TOL: UNLESS SPECIFIED.

.XX

.XXX

.XXXX

ANGLE

DRN

MATERIAL:

.005

Connectivity Solutions

CRITICAL

299 Johnson Ave. Ste. 100

Waseca, MN 56093

1-800-247-8256

IINTERPRET DRAWING

PER MIL-STD-100.

DIMENSIONS ARE IN

INCHES AND INCLUDE

FINISH THICKNESS

UNLESS OTHERWISE

SPECIFIED.

3. MAX PANEL THK .125

EMERSON

J.CRAWFORD

CHK

TM

1/29/11

C.WALLACE

QUALITY

FINISH:

MANUF

Network Power

TITLE:

2/7/11

2. SOCKET CONTACT CONCENTRIC TWINAX/

TRIAX 2-LUG TRB SOLDER POT

BULKHEAD MOUNT RECEPTACLE

.443

.439

BJ77TL

RECOMMENDED

PANEL CUTOUT

N/A

PRO/E FILE NO.

SIZE

APPROVED

CAGE CODE

DRAWING NO.

REV.

1. FINISH: TFS-1A (NICKEL)

C 14949

SCALE

DATE

305-0508

SHEET

K

SURFACE AREA

305-0508

DO NOT SCALE DWG

8/1

10/10/83

1 OF 2

NOTES: UNLESS OTHERWISE SPECIFIED.
