CY23S08SXI-2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> CY23S08SXI-2

CY23S08SXI-2: Description23S SERIES, PLL BASED CLOCK DRIVER, 8 TRUE OUTPUT(S), 0 INVERTED OUTPUT(S), PDSO16, 0.150 INCH, LEAD FREE, MS-012, SOIC-16; Categorylogic logic; File Size958KB，12 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

CY23S08SXI-2 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	CY23S08SXI-2	-	-	View	Buy Now

CY23S08SXI-2 Overview

23S SERIES, PLL BASED CLOCK DRIVER, 8 TRUE OUTPUT(S), 0 INVERTED OUTPUT(S), PDSO16, 0.150 INCH, LEAD FREE, MS-012, SOIC-16

CY23S08SXI-2 Parametric

Parameter Name	Attribute value
Parts packaging code	SOIC
package instruction	SOP,
Contacts	16
Reach Compliance Code	unknown
series	23S
Input adjustment	STANDARD
JESD-30 code	R-PDSO-G16
length	9.893 mm
Logic integrated circuit type	CLOCK DRIVER
Number of functions	1
Number of inverted outputs
Number of terminals	16
Actual output times	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Output characteristics	3-STATE
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
propagation delay (tpd)	0.275 ns
Certification status	COMMERCIAL
Same Edge Skew-Max（tskwd）	0.3 ns
Maximum seat height	1.727 mm
Maximum supply voltage (Vsup)	3.6 V
Minimum supply voltage (Vsup)	3 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
width	3.8985 mm
minfmax	140 MHz
Base Number Matches	1
