6.2mm (0.25INCH) FOUR DIGIT NUMERIC DISPLAY
CA25-11SRWA
SUPER BRIGHT RED
l
0.25 INCH DIGIT HEIGHT
Features
Description
l
LOW CURRENT OPERATION.
The Super Bright Red source color devices are made with
Gallium Aluminum Arsenide Red Light Emitting Diode.
l
EXCELLENT CHARACTER APPEARANCE.
l
I.C. COMPATIBLE.
l
EASY MOUNTING ON P.C. BOARDS OR SOCKETS.
l
CATEGORIZED FOR LUMINOUS INTENSITY.
l
MECHANICALLY RUGGED.
l
STANDARD : GRAY FACE, WHITE SEGMENT.
Package Dimensions & Internal Circuit Diagram
D
i
g
i
t
a
l
l
y
s
i
g
n
e
d
b
y
N
e
n
u
p
h
a
r
c
n
=
N
e
n
u
p
h
a
r
,
o
u
=
d
3
e
,
o
=
d
i
s
p
l
a
y
,
c
=
C
N
D
a
t
e
:
2
0
0
3
.
0
5
.
1
1
1
4
:
3
3
:
4
6
+
0
8
'0
0
'R
e
a
s
o
n
:
D
o
c
u
m
e
n
t
i
s
c
e
r
t
i
f
i
e
d
Notes:
1. All dimensions are in millimeters (inches), Tolerance is
±0.25(0.01")unless
otherwise noted.
2. Specifications are subject to change without notice.
SPEC NO:DSAC6735
APPROVED : J. Lu
REV NO: V.1
CHECKED :Joe Lee
DATE:MAY/11/2003
DRAWN:L.ZHANG
PAGE: 1 OF 3
Selection Guide
P ar t N o .
C A25-11SRWA
Dic e
SUPER BRIGHT RED (GaAlAs)
L en s Ty p e
WHITE D IFFUSED
Mi n .
Iv (u c d )
@ 10m A
Ty p .
D es c r i p t i o n
C ommon Anode
8000
26800
Electrical / Optical Characteristics at T
A
=25°C
°
Sy m b o l
λ
p e a k
λ
D
∆λ
1/2
C
V
F
I
R
P ar am et er
Peak Wavelength
D omi nate Wavelength
D ev i c e
Ty p .
660
640
20
45
1.85
Max .
Un its
nm
nm
nm
pF
Tes t C o n d i t i o n s
I
F
=20mA
I
F
=20mA
I
F
=20mA
V
F
=0V;f=1MHz
I
F
=20mA
V
R
= 5V
Super Bri ght Red
Super Bri ght Red
Spectral Li ne Half-wi dth Super Bri ght Red
C apaci tance
Forward Voltage
Reverse C urrent
Super Bri ght Red
Super Bri ght Red
Super Bri ght Red
2.5
10
V
uA
Absolute Maximum Ratings at T
A
=25°C
°
P ar am et er
D C Forward C urrent
Power di ssi pati on
S u p er B r i g h t R ed
100
155
-40
°
C To +85
°C
5
30
Un its
mW
mA
V
mA
Peak Forward C urrent [1]
Operati ng/Storage Temperature
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 2mm below package base.
Reverse Voltage
Lead Solder Temperature [2]
260
°
C For 5 Seconds
SPEC NO:DSAC6735
APPROVED : J. Lu
REV NO: V.1
CHECKED :Joe Lee
DATE:MAY/11/2003
DRAWN:L.ZHANG
PAGE: 2 OF 3
