CIC31J800BE datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> filter> CIC31J800BE

CIC31J800BE: DescriptionPassive Filter; CategoryAnalog mixed-signal IC filter; File Size312KB，4 Pages; ManufacturerSAMSUNG; Websitehttp://www.samsung.com/Products/Semiconductor/; Environmental Compliance

Download Datasheet Parametric View All

CIC31J800BE Overview

Passive Filter

CIC31J800BE Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	1206
Reach Compliance Code	compliant
shell code	1206
structure	Chip Bead
Maximum DC resistance	0.02 Ω
maximum frequency	100 MHz
minimum frequency	100 MHz
high	1.1 mm
JESD-609 code	e3
length	3.2 mm
Material	Ferrite
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
method of packing	TR, Embossed Plastic, 7 Inch
physical size	L3.2XB1.6XH1.1 (mm)/L.126XB.063XH.0433 (inch)
Rated current	4 A
series	CIC31
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrier
width	1.6 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Chip Bead

CIC Series- CIC31 (3216 EIA 1206)

For High Current

The CIC Series can be used in high current owing to their

low DC resistance.

They can match power lines to maximum of

A DC

FEATURES

Smallest beads used in high current.

(CIC: ~ 3A

)

APPLICATION

Suppression of noise in power line

SPECIFICATION

Operating temperature range –55 to +125°C

Storage temperature range

–10 to +40°C

Relative humidity 30 to 70%

PRODUCT IDENTIFICATION

(1)

(2)

(3)

(4)

(2)

(3)

(4)

300

(5)

(6)

(7)

Chip Beads

For High current(~3A)

Dimension

Material Code

P: Broad impedance, especially suppresses noise in

the

10~200MHz range

J: Suppresses noise in

the

100~300MHz range

(5) Nominal impedance (300:30

Ω, 221:220Ω )

(6) Thickness option(N:Standard, A:Thinner than standard, B:Thicker than standard)

(7) Packaging(C:paper tape, E:embossed tape)
